4G-Ready x86 Computers for Tough Environments


In the Industrial IoT age, industrial computers are increasingly being deployed in remote and harsh environments to collect data from field devices for effective monitoring and preventive maintenance.

Moxa’s 4G-enabled, Intel Atom® -based IIoT edge computers are designed to operate reliably in extreme conditions, such as continuous exposure to low or high temperatures, humidity, high vibration or power surges, making them perfect for heavy industry, solar grid, water/wastewater, oil & gas, transportation, and marine applications.

Solution Brochure

Learn more about Moxa’s rugged wireless x86 edge computers


Key Features

Rugged Design

  • Industrial-grade fanless design
  • HALT validated for extreme environment

Robust Connectivity

  • 4G LTE-enabled with wide operating temperature
  • Carrier approval (Verizon, AT&T)*

*Certification is underway; check the product page for the most up-to-date certification status

Compact with Rich I/O

  • Built-in 4 DIs and 4 DOs to save cost and space
  • Up to 4 Giga LAN and 4 serial ports
  • Up to 2 miniPCIe sockets

Industry Certified

  • Certified as per ATEX/IECEx Zone 2 and UL Class I Division 2 standards
  • Certified as per DNV GL
  • Microsoft Azure Certified for IoT

Applications

Solar Power Monitoring in Western Europe

Control and Communication of Solar Energy Inverters

A major inverter supplier for large-scale PV power plants uses Moxa’s rugged edge computers to communicate with and control inverters in harsh, outdoor environments.


Factory Automation in Asia

Machine Data Acquisition for Preventive Maintenance

A system integrator uses Moxa’s compact edge computers to collect data from different brands of PLCs without having to modify or update the existing system.


Select Your x86 IIoT Edge Computer

Model
CPU
Memory
Storage
OS
Communication Interfaces
miniPCIe Socket
Display Interface
Industrial Certifications
Operating Temperature
Dimensions
Datasheet
Intel Atom® E3815/E3826/E3845 Intel Atom® E3826/E3845 Intel Atom® E3826/E3845 Intel Atom® E3826/E3845 Intel Atom® E3826/E3845
Up to 8 GB Up to 8 GB Up to 8 GB Up to 8 GB Up to 8 GB
mSATA CFast + SD CFast + SD CFast CFast
WS7E / Windows 10 IoT / Debian 8 WS7E / Windows 10 IoT / Debian 8 WS7E / Windows 10 IoT / Debian 8 WS7E / Windows 10 IoT / Debian 8 WS7E / Windows 10 IoT / Debian 8
2 Serial, 2 Giga LAN, 4 DIs, 4 DOs, 1 USB 3.0, 2 USB 2.0 2 Giga LAN, 2 USB 2.0 2 Serial, 4 Giga LAN, 4 DIs, 4 DOs, 2 USB 2.0 2 Serial, 2 Giga LAN, 2 USB 2.0 4 Serial, 4 Giga LAN, 4 DIs, 4 DOs, 2 USB 2.0
2 (1 Cellular, 1 Wi-Fi) - 1 (Cellular or Wi-Fi) - 1 (Cellular or Wi-Fi)
1 HDMI 1 VGA, 1 DisplayPort 1 VGA, 1 DisplayPort 1 VGA 1 VGA
EN 61000-6-2/4 CID2, ATEX Zone 2, IECEx, IEC 60945, DNV GL CID2, ATEX Zone 2, IECEx, IEC 60945, DNV GL CID2, ATEX Zone 2, IECEx, IEC 60945, DNV GL CID2, ATEX Zone 2, IECEx, IEC 60945, DNV GL
  • -40 to 85°C
  • -40 to 70°C
-40 to 70°C -40 to 70°C -40 to 70°C -40 to 70°C
150 x 120.2 x 48.8 mm 132 x 122 x 68 mm 132 x 122 x 87 mm 132 x 122 x 68 mm 132 x 122 x 87 mm
