Simplify Digital Transformation of Your IIoT Systems

Rapid globalization and digital transformation have led to industrial operators adopting IIoT applications to enhance operational efficiency and maximize revenue. An IDC report gives insights on the benefits for organizations with a unified set of capabilities that connect OT data to the cloud, illustrating how companies with a holistic strategy will be in a good position to reap the value potential of their operational data. To help our customers rapidly enter the IIoT world, Moxa provides secure, reliable, and easy-to-use sensor-to-cloud IIoT solutions that can effortlessly transform data into actionable insights. Our robust and ready-to-run IIoT gateways, with value-added functions for reducing programming efforts, are ideal drivers of digital transformation in your IIoT systems.

  • Security

    Security

    Trusted Platform Module (TPM) and Secure Boot ensure effective protection against cyberattacks while resume file transmission and over-the-air (OTA) upgrades ensure continuous availability
  • Ease of Use

    Ease of Use

    Built-in traffic monitoring and diagnosis with an intuitive UI help monitor and troubleshoot communication issues for both IT (Azure, AWS, MQTT) and OT (Modbus) applications, bridging the gap between OT and IT systems and reducing programming efforts
  • Deep Azure Integration

    Deep Azure Integration

    Azure IoT Hub Device Provisioning Service (DPS) and Device Twins help manage the device using direct methods or a device twin with minimal human intervention
Moxa Solutions
Connectivity
Telemetry Message
Azure IoT Edge
OPC UA Server
Modbus RTU/TCP Master/Client
Modbus TCP Server (Slave)
Number of tags supported
Moxa Device Integration
Device Management
Cloud Device Management Integration
Moxa DLM
OTA Upgrade
Edge Computing
Performance
Zero-code Data Preprocessing
IoT Edge Module/ Function Management
Cybersecurity
TPM/Secure Boot/ Disk Encryption
HTTPS
Role-based Account Management
AIG-101 Series
Cost-effective IIoT gateways with built-in data preprocessing
AIG-301 Series
Advanced IIoT gateways that can be programmed
AIG-501 Series
High-performance IIoT gateways for complex data handling
Azure IoT Device, AWS IoT Core, MQTT Client Azure IoT Device, Azure IoT Edge, AWS IoT Core, MQTT Client, Sparkplug B Azure IoT Device, Azure IoT Edge, AWS IoT Core, MQTT Client, Sparkplug B
RTU/ASCII/TCP RTU/ASCII/TCP RTU/ASCII/TCP
1,500 2,048 2,048
ioLogik E1200, UPort 1100/1200
Azure: Direct Methods
AWS: Job
MQTT: Remote API Invocations
Azure: Device/Module Twins, Direct Methods, DPS
AWS: Shadow, Job
MQTT: Remote API Invocations
Azure: Device/Module Twins, Direct Methods, DPS
AWS: Shadow, Job
MQTT: Remote API Invocations
Arm Cortex-A8 1 GHz, 1 GB RAM, 8 GB eMMC Armv7 dual-core 1 GHz, 2 GB RAM, 16 GB eMMC Intel Atom E3845, 4 GB RAM, 32 GB Cfast

Featured Case Study

IIoT Technology for Efficient Management of Commercial Solar Power Plants

Commercial solar farms are typically scattered over remote sites. IIoT technology is emerging as a popular solution to efficiently monitor and manage the remotely distributed assets on a solar farm. Check out how Moxa’s ready-to-run IIoT gateways are bridging the gap between OT and IT systems to simplify remote data transfer in commercial solar farms.
