Cloud-ready IIoT Edge Gateways

Meet Our Cloud-ready IIoT Edge Gateways

Moxa’s cloud-ready IIoT edge gateway family consists of industrial computers that are optimized for edge computing applications in the solar power, water and wastewater, oil and gas, and factory automation sectors. Our supplementary IIoT software, ThingsPro®, simplifies the connection of edge data to the cloud. It provides multiple connectivity options, including Modbus and generic MQTT/HTTPS protocols, and comes with built-in clients to connect to AWS and Azure cloud services.

Designed for remote monitoring and telemetry applications in the field, these compact IIoT edge gateways are equipped with a power-efficient Intel Atom® or Arm-based processor and can provide reliable wireless connectivity in environments with temperatures ranging from -40 to 70°C.

Software Features

Private Cloud Ready

Easily integrate on-premise cloud with ThingsPro through:
- Generic MQTT
- HTTPS support
- RESTful API support
- C/Python API support
Public Cloud Ready

Moxa's ThingsPro comes with built-in clients for:
- AWS IoT Core
- Azure IoT Hub
- Ignition
- Wonderware Online
- Alibaba Cloud IoT Platform
Edge Intelligence Ready

Our IIoT edge gateways are optimized to work with edge software, including:
- Azure IoT Edge
- Rapid development on ThingsPro software

Hardware Features

Rugged Design
- Industrial-grade fanless design
- Metal housing
- C1D2, ATEX/IECEx Zone 2, and DNV GL certified
Robust Connectivity
- Reliable 4G LTE in temperatures of -40 up to 70°C
- Supports dual SIM or Wi-Fi/LTE redundancy
Long-term Support

Backed by an industry-leading hardware warranty
- Arm-based computers: 5 years
- x86 computers: 3 years

Your Guide to IIoT Applications

Discover how Moxa's IIoT edge gateways simplify the integration of edge data with cloud services in:

Solar power plant monitoring and control systems
Residential solar power monitoring systems
Remote asset management for ITS
Geographic information systems for natural disaster warning
Oil and gas wellhead monitoring
Factory automation

Guidebook

Learn more about Moxa’s IIoT edge gateways and ThingsPro software

FAQs

Connect to Your Private Cloud
Connect to a Public Cloud
Enable Edge Intelligence

What is Moxa’s ThingsPro Software Suite and how does it work?
Moxa’s ThingsPro Software Suite is a collection of software programs designed to simplify IIoT gateway application development. It currently includes two programs:
- ThingsPro Gateway: A software for IIoT edge gateways, which provides an easy-to-use GUI for Modbus data logging, tag-based data acquisition, LTE connectivity, and MQTT/HTTPS communication. Also included are C and Python APIs for developing your own applications, and client interfaces for multiple cloud-based services.
- ThingsPro Server: A cloud-based service to locate and manage your IIoT edge gateways. It can be hosted on cloud platforms such as AWS and offers RESTful APIs for integrating information with your dashboards.
To learn more, watch the ThingsPro introduction video.
Which devices and what kind of OS can ThingsPro run on?

ThingsPro Gateway Software is currently supported on Moxa’s UC-8100 and MC-1121 Series IIoT edge gateways that run Debian Linux OS. Additional devices will be supported in the future.

Check the ThingsPro product page for the most up-to-date information.
What protocols does ThingsPro support for connecting to a private cloud?

ThingsPro Gateway allows you to connect to your own cloud by using HTTPS protocol and MQTT broker.

For details, refer to these technical notes.

Does ThingsPro provide APIs to develop my own programs on Moxa's edge gateways?
ThingsPro Gateway Software provides C/Python/RESTful APIs for users to develop their own data-processing programs on Moxa's edge gateways. For more details, refer to the following technical notes and guides:
- Technical notes
- User’s manuals and programmer’s guide
If I have a number of geographically-distributed edge gateways, how can I effectively manage them?

ThingsPro Server allows users to locate and remotely access gateway devices with a web-based UI. Device management functions include firmware upgrades, configuration changes, and user-program uploads, on demand, or as per a pre-determined schedule. ThingsPro Server also provides an account management tool for role-based access control.

For more details, refer to these technical notes.
Is there a programmer’s guide available for ThingsPro?
For programming guidelines and instructions on developing applications, refer to the following:
- User’s manuals and programmer’s guide
- Technical notes

What is Moxa’s ThingsPro Software Suite and how does it work?
Moxa’s ThingsPro Software Suite is a collection of software programs designed to simplify IIoT gateway application development. It currently includes two programs:
- ThingsPro Gateway: A software for IIoT edge gateways, which provides an easy-to-use GUI for Modbus data logging, tag-based data acquisition, LTE connectivity, and MQTT/HTTPS communication. Also included are C and Python APIs for developing your own applications, and client interfaces for multiple cloud-based services.
- ThingsPro Server: A cloud-based service to locate and manage your IIoT edge gateways. It can be hosted on cloud platforms such as AWS and offers RESTful APIs for integrating information with your dashboards.
To learn more, watch the ThingsPro introduction video.
Which devices and what kind of OS can ThingsPro run on?

ThingsPro Gateway Software is currently supported on Moxa’s UC-8100 and MC-1121 Series IIoT edge gateways that run Debian Linux OS. Additional devices will be supported in the future.

Check the ThingsPro product page for the most up-to-date information.
Which public cloud services does ThingsPro support, and how do I connect to them?

ThingsPro Gateway includes GUIs to help you set up connections and access popular cloud-based services in just a few clicks. It currently supports AWS, Azure, Ignition Edge (Sparkplug), Schneider Wonderware Online, and generic MQTT/HTTPS services.

To learn more, refer to these technical notes.

Does ThingsPro provide APIs to develop my own programs on Moxa's edge gateways?
ThingsPro Gateway Software provides C/Python/RESTful APIs for users to develop their own data-processing programs on Moxa's edge gateways. For more details, refer to the following technical notes and guides:
- Technical notes
- User’s manuals and programmer’s guide
If I have a number of geographically-distributed edge gateways, how can I effectively manage them?

ThingsPro Server allows users to locate and remotely access gateway devices with a web-based UI. Device management functions include firmware upgrades, configuration changes, and user-program uploads, on demand, or as per a pre-determined schedule. ThingsPro Server also provides an account management tool for role-based access control.

For more details, refer to these technical notes.
Is there a programmer’s guide available for ThingsPro?
For programming guidelines and instructions on developing applications, refer to the following:
- User’s manuals and programmer’s guide
- Technical notes

How do Moxa’s IIoT edge gateways enable edge intelligence?

Moxa's IIoT edge gateways currently support AWS Greengrass and Microsoft IoT Edge to enable edge intelligence, thereby making it easy to perform machine learning tasks on these edge computers.
Which Moxa devices support AWS Greengrass and Microsoft IoT Edge?
- Models that have been pretested to work with AWS Greengrass:
  - MC-1122 (Windows 10)
  - UC-8112-ME-T-US-LTE-LX1 (Debian Linux)
- Models that have been pretested to work with Microsoft IoT Edge:
  - MC-1122 (Win 10 LTSB)
  - UC-8112-ME-T-US-LTE-LX1 (Debian Linux)
Can I install AWS Greengrass/Microsoft IoT Edge on my existing Moxa devices?

You can install either AWS Greengrass or Microsoft IoT Edge on Moxa edge computers listed in Which Moxa devices support AWS Greengrass and Microsoft IoT Edge

For detailed installation instructions, refer to these technical notes.

Can I install ThingsPro along with AWS Greengrass or Microsoft IoT Edge on Moxa’s IIoT edge gateways?

This depends on the CPU and RAM specification of the IIoT edge gateway and the applications you intend to run on the gateway. For additional questions regarding programming on Moxa’s IIoT edge gateways, contact Moxa.
Where can I find programming guides for AWS Greengrass or Microsoft IoT Edge?
For programming resources for AWS Greengrass and Microsoft IoT Edge, refer to the resources from Amazon and Microsoft:
- AWS Greengrass
- Microsoft IoT Edge

Choose an IIoT Edge Gateway

Model
CPU
Memory
Interfaces
Wireless Connectivity
Hazardous Location Certifications
Cloud Connectivity Support (Optional)
Datasheet

MC-1121	UC-2104	UC-3101/3111	UC-5112	UC-8112A-ME-T
Intel Atom® E3845 Quad-Core 1.91 GHz	TI AM3352 Arm Cortex-A8 600 MHz	TI AM3352 Arm Cortex-A8 1 GHz	TI AM3352 Arm Cortex-A8 1 GHz	TI AM3352 Arm Cortex-A8 1 GHz
4 GB	256 MB	512 MB	512 MB	1 GB
2 Serial, 4 Giga LAN, 4 DIOs, 2 USB 2.0	1 LAN	1 or 2 Serial, 2 LAN, 1 USB 2.0	4 Serial, 2 LAN, 4 DIOs, 2 CAN, 1 USB 2.0	2 Serial, 2 LAN, 1 USB 2.0
Wi-Fi or LTE Cat 4	Wi-Fi or LTE Cat 1	Wi-Fi & LTE Cat 1 with dual SIM slots	Wi-Fi or LTE Cat 1 with dual SIM slots	Wi-Fi or LTE Cat 4
C1D2, ATEX & IECEx Zone 2, DNV GL	-	C1D2, ATEX & IECEx Zone 2	-	C1D2, ATEX & IECEx Zone 2
AWS Greengrass* Azure IoT Edge ThingsPro Software	ThingsPro Software	ThingsPro Software	ThingsPro Software	Azure IoT Edge ThingsPro Software

*Certification process is underway
