1

+13 to +30 V for state 1
-30 to +1 V for state 0
Max. input current: 8 mA

VPort P07-3 Series: 5-pin male M12 connector with 20 cm cable
VPort 07-3 Series: DB9 male

VPort P07-3 Series: 1

VPort 07-3 Series: 1

TCP/IP
IPv4/IPv6
UDP
HTTP
RTP/RTSP
ARP
UPnP
FTP
TFTP
SFTP
NTP Client
DNS
QoS
IGMP v3
ICMP
SNMPv1/v2c/v3
DHCP Opt66/67
HTTPS

User-level password protection

IP address

Secure Boot

HTTPS
SSH

1

VPort P07-3 Series: PoE (IEEE 802.3af)

VPort 07-3 Series: 12/24 VDC

VPort P07-3: 48 VDC @ 0.137 A
VPort 07-3: 24 VDC @ 0.27 A; 12 VDC @ 0.59 A

VPort 07-3 Series: DB9 connector

1/3-in 3-megapixel progressive scan CMOS

VPort 07/P07-3x24M Series: f=2.4 mm, F2.0, Diagonal 139°, Horizontal 110°, Vertical 81°
VPort 07/P07-3x36M Series: f=3.6 mm, F1.6, Diagonal 97°, Horizontal 75°, Vertical 55°
VPort 07/P07-3x42M Series: f=4.2 mm, F1.6, Diagonal 82°, Horizontal 64°, Vertical 47°
VPort 07/P07-3x60M Series: f=6.0 mm, F1.8, Diagonal 57°, Horizontal 43°, Vertical 32°
VPort 07/P07-3x80M Series: f=8.0 mm, F1.6, Diagonal 41°, Horizontal 33°, Vertical 24°

Color: 0.2 lux, at F1.2 (Gain High, 50 IRE, 1/30 sec)

Internal

ATW/AWB

Auto, Fixed (1/30 to 1/25000 sec)

Maximum 50 dB (AGC off; DNR on)

Built-in 2D/3D DNR

100 dB

2X, 4X, 8X, 16X

Automatic, 50 Hz, 60 Hz modes

Flip, Mirror, 90°, 180°, 270° rotation

Manual tuning with saturation, sharpness, and contrast

Pan: ±15°, Tilt: 20° to 90° for 2.4mm lens, 0° to 90° for other lens (controlled manually)

H.265 (MPEG-H part 2/HEVC), H.264 (ISO/IEC 14496-10/AVC), or MJPEG

via Ethernet

4 independent video streams

Read more

Note: Once the 3-megapixels resolution is configured in one stream, all video streams will be only up to maximum 20 FPS at all resolutions due to sensor limitation.

DynaStream™ support for changing the video frame rate automatically
CBR Pro™ for good image quality in limited bandwidth transmissions
3 privacy mask areas provided
Adjustable image size and quality
Timestamp and text overlay
OSD (On Screen Display) position adjustable
LDC (Lens distortion correction) for less image warp
Maximum of 10 simultaneous unicast connections, 50 multicast clients

Mono, PCM (G.711)
AAC

VPort 07/P07-3MxxM Series: 1 x built-in microphone
VPort 07-3LxxM Series: 1 x line-in, with DB9 connector
VPort P07-3LxxM Series: 1 x line-in, with M12 connector

ONVIF Profile S, T, M

Camera tampering detection

3 independently configurable areas

JPEG snapshots for pre/trigger/post alarm images

HTTP event servers for setting customized alarm actions

Automatic transfer of stored images via FTP as event-triggered actions

50 MB video buffer for JPEG snapshot images

8 GB

Windows 10 or above

Internet Explorer 11 or above
Chrome: Version 118 or above
Microsoft Edge: Version 118 or above

DirectX 12 or above

IP66 rain and dust protection
Metal housing, PC dome cover
IK8 vandal resistant protection
Built-in heater for dome cover demist

110 x 115.5 x 61.8 mm (4.33 x 4.53 x 2.43 in)

620 g (1.37 lb)

Panel mounting

PCB conformal coating is optional and provided on request. If conformal coating is required, please contact Moxa.

Standard Models: -40 to 55°C (-40 to 131°F)
Wide Temp. Models: -40 to 70°C (-40 to 158°F)

-40 to 85°C (-40 to 185°F)

5 to 95% (non-condensing)

IEC 60529, IP66

EN 62262, IK8

2000 m
Note: Please contact Moxa if you require products guaranteed to function properly at higher altitudes.

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV
IEC 61000-4-6 CS: 10 V
IEC 61000-4-8 PFMF

IEC 60068-2-31

EN 45545-2

UL 62368-1

IEC 60068-2-27, IEC 61373, EN 50155

IEC 60068-2-64, IEC 61373, EN 50155

EN 50155 (complies with a portion of EN 50155 specifications)

5 years

See www.moxa.com/tw/warranty
