Home Products Industrial Computing x86 Computers DA-PWR-200 Power Module Series DA-PWR-200-HV
MOXA

x86 Computers

Moxa’s x86 industrial-grade fanless computers have passed rigorous tests and strictly adhere to industrial standards to ensure they can provide long-lasting, reliable operation even in harsh environments, making them perfect for a variety of industrial-automation applications.

DA-PWR-200-HV
DA-PWR-200 Power Module Series

Hot-swappable 100 to 240 VAC/VDC power module with system power input and terminal block for DA-920E Series computers

Power Parameters

  • Input Voltage

    • DA-PWR-200-HV: 100 to 240 VAC/VDC
      DA-PWR-200-WV: 24 to 110 VDC

  • Operating Voltage

    • DA-PWR-200-HV: 90 to 264 VAC/VDC
      DA-PWR-200-WV: 21.6 to 121 VDC

  • Overload Current Protection

    • Supported

  • Overload Voltage Protection

    • Supported

  • Overload Temperature Protection

    • Supported
Physical Characteristics

  • Weight

    • DA-PWR-200-HV: 820g (1.8 lbs)
      DA-PWR-200-WV: 820g (1.8 lbs)
Environmental Limits

  • Operating Temperature

    • -40 to 85°C (-40 to 185°F)
MTBF

  • Time

    • DA-PWR-200-HV: 3,886,750 hrs
      DA-PWR-200-WV: 3,227,791 hrs

  • Standards

    • Telcordia SR-332 Standard Issue 4
Warranty
