RM-G4000 Module Series

Ethernet modules for RKS-G4028 modular managed switches

moxa-rm-g4000-module-series-image-(1).jpg | Moxa
moxa-rm-g4000-module-series-image-1-(1).jpg | Moxa
moxa-rm-g4000-module-series-image-2-(1).jpg | Moxa
moxa-rm-g4000-module-series-image-3-(1).jpg | Moxa
moxa-rm-g4000-module-series-image-4-(1).jpg | Moxa

Features and Benefits

  • -40 to 75°C operating temperature range
  • IEC 61850-3 and IEEE 1613 compliant

Certifications

  • moxa-ce-certification-logo-image.png | Moxa
  • moxa-fcc-certification-logo-image.png | Moxa

Contact Sales

Introduction

The RM-G4000 Module Series includes Gigabit and Fast Ethernet modules for the RKS-G4000 Series rack-mount Ethernet switches. Each RM-G4000 Series module supports up to 8 ports with a variety of interface types including TX, MSC, SSC, and MST media types. Additionally, the RM-G4000-8GPoE and RM-G4000-8PoE modules provide the RKS-G4000 Series PoE models with high-capacity PoE functionality. IEEE 1588 interface modules provide hardware-based PTP functions for precise time synchronization across the network.

  • 10/100BaseT(X) Ports (RJ45 connector)

    RM-G4000-8TX: 8
    RM-G4000-2MSC4TX: 4
    RM-G4000-2MST4TX: 4
    RM-G4000-2SSC4TX: 4
    RM-G4000-4MSC2TX: 2
    RM-G4000-4MST2TX: 2
    RM-G4000-4SSC2TX: 2

  • 10/100/1000BaseT(X) Ports (RJ45 connector)

    RM-G4000-8GTX: 8

  • 100/1000BaseSFP Slots

    RM-G4000-8GSFP: 8

  • 100BaseSFP Slots

    RM-G4000-8SFP: 8

  • 100BaseFX Ports (multi-mode SC connector)

    RM-G4000-6MSC: 6
    RM-G4000-2MSC4TX: 2
    RM-G4000-4MSC2TX: 4

  • 100BaseFX Ports (multi-mode ST connector)

    RM-G4000-6MST: 6
    RM-G4000-2MST4TX: 2
    RM-G4000-4MST2TX: 4

  • 100BaseFX Ports (single-mode ST connector)

    RM-G4000-6SSC: 6
    RM-G4000-2SSC4TX: 2
    RM-G4000-4SSC2TX: 4

  • PoE Ports (10/100/1000BaseT(X), RJ45 connector)

    RM-G4000-8GPoE: 8

  • PoE Ports (10/100BaseT(X), RJ45 connector)

    RM-G4000-8PoE: 8

  • Optical Fiber

  • Power Consumption (Max.)

    RM-G4000-8TX: 4.22 W
    RM-G4000-8GTX: 4.22 W
    RM-G4000-8PoE: 4.75 W
    RM-G4000-8GPoE: 4.75 W
    RM-G4000-8SFP: 6.91 W
    RM-G4000-8GSFP: 6.91 W
    RM-G4000-6MSC: 4.61 W
    RM-G4000-6MST: 4.61 W
    RM-G4000-6SSC: 5.47 W
    RM-G4000-2MSC4TX: 2.88 W
    RM-G4000-2MST4TX: 2.88 W
    RM-G4000-2SSC4TX: 3.17 W
    RM-G4000-4MSC2TX: 3.74 W
    RM-G4000-4MST2TX: 3.74 W
    RM-G4000-4SSC2TX: 4.03 W

  • Weight

    RM-G4000-8TX: 300 g (0.66 lb)
    RM-G4000-8GTX: 300 g (0.66 lb)
    RM-G4000-8PoE: 500 g (1.10 lb)
    RM-G4000-8GPoE: 500 g (1.10 lb)
    RM-G4000-8SFP: 400 g (0.88 lb)
    RM-G4000-8GSFP: 400 g (0.88 lb)
    RM-G4000-6MSC: 400 g (0.88 lb)
    RM-G4000-6MST: 400 g (0.88 lb)
    RM-G4000-6SSC: 400 g (0.88 lb)
    RM-G4000-2MSC4TX: 400 g (0.88 lb)
    RM-G4000-2MST4TX: 400 g (0.88 lb)
    RM-G4000-2SSC4TX: 400 g (0.88 lb)
    RM-G4000-4MSC2TX: 400 g (0.88 lb)
    RM-G4000-4MST2TX: 400 g (0.88 lb)
    RM-G4000-4SSC2TX: 400 g (0.88 lb)

  • Time

    RM-G4000-8TX: 12,132,675 hrs
    RM-G4000-8GTX: 12,132,675 hrs
    RM-G4000-8PoE: 2,063,404 hrs
    RM-G4000-8GPoE: 2,063,404 hrs
    RM-G4000-8SFP: 3,005,803 hrs
    RM-G4000-8GSFP: 3,005,803 hrs
    RM-G4000-6MSC: 2,183,161 hrs
    RM-G4000-6MST: 2,183,161 hrs
    RM-G4000-6SSC: 2,183,161 hrs
    RM-G4000-2MSC4TX: 2,891,502 hrs
    RM-G4000-2MST4TX: 2,891,502 hrs
    RM-G4000-2SSC4TX: 2,891,502 hrs
    RM-G4000-4MSC2TX: 2,469,891 hrs
    RM-G4000-4MST2TX: 2,469,891 hrs
    RM-G4000-4SSC2TX: 2,469,891 hrs

  • Standards

    Telcordia (Bellcore), GB

Support Documents

Name Type Version Release Date
Datasheet for RM-G4000 Module Series
705.3 KB
Datasheet v1.1 Jan 12, 2023 Jan 12, 2023

Available Models (15)

Show Images
moxa-rm-g4000-4msc2tx-image.jpg | MoxaRM-G4000-4MSC2TXmoxa-rm-g4000-4ssc2tx-image.jpg | MoxaRM-G4000-4SSC2TXmoxa-rm-g4000-4mst2tx-image.jpg | MoxaRM-G4000-4MST2TXmoxa-rm-g4000-8gpoe-image.jpg | MoxaRM-G4000-8GPoE
10/100/1000BaseT(X) Ports8
(IEEE 802.3bt PoE)
10/100BaseT(X) Ports222
100/1000BaseSFP Ports
100BaseSFP Ports
100BaseFX Ports Multi-mode, SC Connector4
100BaseFX Port Multi-mode, ST Connector4
100BaseFX Port Single-mode, SC Connector4
Add to QuoteView BagAdd to QuoteView BagAdd to QuoteView BagAdd to QuoteView Bag
moxa-rm-g4000-6ssc-image.jpg | MoxaRM-G4000-6SSCmoxa-rm-g4000-8tx-image.jpg | MoxaRM-G4000-8TXmoxa-rm-g4000-8gtx-image.jpg | MoxaRM-G4000-8GTXmoxa-rm-g4000-8sfp-image.jpg | MoxaRM-G4000-8SFP
10/100/1000BaseT(X) Ports8
10/100BaseT(X) Ports8
100/1000BaseSFP Ports
100BaseSFP Ports8
100BaseFX Ports Multi-mode, SC Connector
100BaseFX Port Multi-mode, ST Connector
100BaseFX Port Single-mode, SC Connector6
Add to QuoteView BagAdd to QuoteView BagAdd to QuoteView BagAdd to QuoteView Bag
moxa-rm-g4000-8poe-image.jpg | MoxaRM-G4000-8PoEmoxa-rm-g4000-2ssc4tx-image.jpg | MoxaRM-G4000-2SSC4TXmoxa-rm-g4000-2msc4tx-image.jpg | MoxaRM-G4000-2MSC4TXmoxa-rm-g4000-6mst-image.jpg | MoxaRM-G4000-6MST
10/100/1000BaseT(X) Ports
10/100BaseT(X) Ports8
(IEEE 802.3bt PoE)
44
100/1000BaseSFP Ports
100BaseSFP Ports
100BaseFX Ports Multi-mode, SC Connector2
100BaseFX Port Multi-mode, ST Connector6
100BaseFX Port Single-mode, SC Connector2
Add to QuoteView BagAdd to QuoteView BagAdd to QuoteView BagAdd to QuoteView Bag
moxa-rm-g4000-8gsfp-image.jpg | MoxaRM-G4000-8GSFPmoxa-rm-g4000-2mst4tx-image.jpg | MoxaRM-G4000-2MST4TXmoxa-rm-g4000-6msc-image.jpg | MoxaRM-G4000-6MSC
10/100/1000BaseT(X) Ports
10/100BaseT(X) Ports4
100/1000BaseSFP Ports8
100BaseSFP Ports
100BaseFX Ports Multi-mode, SC Connector6
100BaseFX Port Multi-mode, ST Connector2
100BaseFX Port Single-mode, SC Connector
Add to QuoteView BagAdd to QuoteView BagAdd to QuoteView Bag
