1
Full/Half duplex mode
Auto MDI/MDI-X connection
Auto negotiation speed

1
Full/Half duplex mode
Auto MDI/MDI-X connection
Auto negotiation speed

Default: V+, V+, V-, V- for pins 4, 5, 7, 8 (Midspan, MDI, Mode B)
Custom DIP switch setting: V+, V+, V-, V- for pins 1, 2, 3, 6 (Endspan, MDI, Mode A)

IEEE 802.3 for 10BaseT
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3af/at for PoE/PoE+ output
IEEE 802.3u for 100BaseT(X)

24/48 VDC

22 to 57 VDC

2.71 A @ 24 VDC

Max. 5.29 W full loading without PDs’ consumption

Max. 60 W for total PD consumption
Max. 60 W for each PoE port

1 removable 4-contact terminal block(s)

Supported

Supported

Metal

IP30

30 x 115 x 78.8 mm (1.19 x 4.53 x 3.10 in)

245 g (0.54 lb)

DIN-rail mounting, Wall mounting (with optional kit)

INJ-24A: 0 to 60°C (32 to 140°F)
INJ-24A-T: -40 to 75°C (-40 to 167°F)

-40 to 85°C (-40 to 185°F)

5 to 95% (non-condensing)

UL 508, EN 60950-1

EN 55032/24

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m
IEC 61000-4-4 EFT: Power: 4 kV; Signal: 2 kV
IEC 61000-4-5 Surge: Power: 3 kV; Signal: 3 kV
IEC 61000-4-6 CS: 10 V
IEC 61000-4-8 PFMF

IEC 60068-2-31

IEC 60068-2-27

IEC 60068-2-6

2,407,739 hrs

Telcordia (Bellcore), GB

5 years

See www.moxa.com/tw/warranty
