5:4

2000:1

16.7M (8-bit/color)

19-inch viewable image

MVA

1280 x 1024

20 ms (gray to gray)

178°/178°

MD-219X/219Z: 300 cd/m²
MD-219Z-HB: 1000 cd/m²

RS-232 ports x 1 (DB9 male)
RS-232/422/485 ports x 1, software-selectable (terminal block)

DVI-D x 1, 29-pin DVI-D connectors (female)
VGA x 1, 15-pin D-sub connector (female)

MD-219Z/MD-219Z-HB: Capacitive Touch (PCAP)
MD-219X: None

MD-219Z/219Z-HB: 4 points

50 bps to 115.2 kbps

5, 6, 7, 8

RTS/CTS, XON/XOFF, ADDC® (automatic data direction control) for RS-485, RTS Toggle (RS-232 only)

None, Even, Odd, Space, Mark

1, 1.5, 2

TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND

Tx+, Tx-, Rx+, Rx-, GND

Data+, Data-, GND

Tx+, Tx-, Rx+, Rx-, GND

100 to 240 VAC, 24 VDC (18 to 30 V)

40 W (max.)

Metal

MD-219X: IP54, front
MD-219X: IP22, rear
MD-219Z: IP54, front
MD-219Z: IP22, rear
MD-219Z-HB: IP66, front
MD-219Z-HB: IP22, rear

429 x 387 x 75 mm (16.89 x 15.24 x 2.95 in)

7,800 g (17.20 lb)

Desktop, Panel mounting, VESA mounting

-15 to 55°C (5 to 131°F)

-20 to 60°C (-4 to 140°F)

5 to 95% (non-condensing)

EN 55032/24

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV
IEC 61000-4-6 CS: 1k V

ABS, CCS, DNV-GL, IEC 60945

UL 60950-1

LCD: 1 year
System: 3 years

See www.moxa.com/tw/warranty
