MC-1220-KL7-T-S: Intel® Core™ i7-7600U Processor (4M Cache, up to 3.90 GHz)
MC-1220-KL5-T-S: Intel® Core™ i5-7300U Processor (3M Cache, up to 3.50 GHz)
MC-1220-KL1-T-S: Intel® Celeron® Processor 3965U (2M Cache, 2.20 GHz)
MC-1220-KL5-T: Intel® Core™ i5-7300U Processor (3M Cache, up to 3.50 GHz)

mSATA slots x 1, SATA 3.0, internal mini-PCIe socket

SODIMM DDR4 slot x 2, up to 32 GB max.

Linux Debian 9, 64-bit, kernel 4.9 (optional via CTOS)
Windows 10 Enterprise LTSC 1809 64-bit (optional via CTOS)

MC-1220-KL7-T-S: Intel® HD Graphics 620
MC-1220-KL5-T-S: Intel® HD Graphics 620
MC-1220-KL1-T-S: Intel® HD Graphics 610
MC-1220-KL5-T: Intel® HD Graphics 620

HDMI x 1, up to 3840 x 2160 resolution at 30 Hz

USB 3.0 hosts x 3, type-A connectors

Reset button

DB9 male

RS-232/422/485 (software selectable)

2 x RS-232/422/485

RTS/CTS, XON/XOFF

50 bps to 115.2 kbps

4 kV contact, 8 kV air

1.5 kV (built-in)

2

Power x 1

2 per port (Tx, Rx)

TxD, RxD, RTS, CTS, GND

Tx+, Tx-, Rx+, Rx-, GND

Tx+, Tx-, Rx+, Rx-, GND

Data+, Data-, GND

Wall mounting (with optional kit), DIN-rail mounting

Metal

134 x 60.4 x 120 mm (5.28 x 2.38 x 4.72 in)

Product only: 1.40 kg (0.63 lb)

RoHS, CRoHS, WEEE

ON/OFF (rear panel)
Reset button

9 to 36 VDC

8 A @ 9 VDC, 2 A @ 36 VDC

72 W

-40 to 70°C (-40 to 158°F)

-40 to 75°C (-40 to 167°F)

5 to 95% (non-condensing)

IEC 60068-2-27

UL 60950-1, UL 62368-1, EN 60950-1, EN 62368-1

EN 55032/35, CISPR 32, FCC Part 15B Class A

ATEX Zone 2, IECEx Zone 2, Class I Division 2

Built-in RTC (real-time clock) with lithium battery backup

510,913 hrs

Telcordia (Bellcore), GB

3 years

See www.moxa.com/tw/warranty
