Screw-fastened Euroblock terminal

1

Nominal value: 24 VDC
Acceptable range: 21.6 to 26.4 VDC

4 A (max.)

20 A (max.)

10 A

12 VDC

6.25 A (max.)

75 W (max.)

10 ms (min.)

100 ms (max.)

15.6 VDC (max.)

9 A (min.)

87%

3k VDC (input to output)
3k VDC (system to field power)

Screw-fastened Euroblock terminal

1

Nominal value: 24 VDC
Acceptable range: 21.6 to 26.4 VDC

3 A (max.)

8 A

3 A (max.)
[Input Voltage - 0.4] VDC (max., matching diode drop at 3 A)

29 VDC (max.)

5 A (min.)

Plastic

42 x 177 x 149.4 mm (1.65 x 6.97 x 5.88 in)

713 g (1.57 lb)

DIN-rail mounting
Rack mounting (with optional kit)

EN 55032/35
EN 61000-6-2/-6-4

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m
IEC 61000-4-4 EFT: Power: (DC) 1 kV; Signal: 1 kV
IEC 61000-4-5 Surge: Power: (DC) 0.5 kV L-N, 1 kV L/N-PE; Signal: 1 kV; IO: 0.5 kV
IEC 61000-4-6 CS: Power: (DC) 10 Vrms; Signal: 10 Vrms
IEC 61000-4-8 PFMF: 30 A/m

UL 61010-1
UL 61010-2-201

IEC 60068-2-27
Half sine wave; acceleration: 15 g; time: 11 ms

IEC 60068-2-6
DIN-rail mounted:
7 mm peak-peak (p-p) (2 to 8.42 Hz), 1 g (8.42 to 150 Hz)
Rack mounted (with optional kit):
7 mm peak-peak (p-p) (2 to 8.42 Hz), 0.5 g (8.42 to 150 Hz)

ISTA 1A

ISTA 1A

954,606 hrs

Telcordia Standard SR-332

-40 to 75°C (-40 to 167°F)
Note: Proper airflow is required in an environment with temperature > 65°C

-40 to 85°C (-40 to 185°F)

5 to 95% (non-condensing)

Up to 2000 m

5 years

See www.moxa.com/tw/warranty
