1

TCP/IP, IPv4, UDP, HTTP, RTP/RTSP, ARP, UPnP, FTP, TFTP, SMTP, NTP Client, DNS, DDNS, QoS, IGMP v3, ICMP, SNMPv1/v2c/v3, DHCP Opt66/67, HTTPS

User-level password protection

IP address

HTTPS

1

PoE (IEEE 802.3af)

0.17 A @ 48 VDC

1/2.7-in HD progressive scan CMOS

VPort P06HC-1V28M Series: f=2.8 mm, F2.0, Diagonal 126°, Horizontal 113°, Vertical 58°
VPort P06HC-1V36M Series: f=3.6 mm, F1.6, Diagonal 99°, Horizontal 94°, Vertical 47°
VPort P06HC-1V42M Series: f=4.2 mm, F1.8, Diagonal 87°, Horizontal 80°, Vertical 43°
VPort P06HC-1V60M Series: f=6.0 mm, F1.6, Diagonal 60°, Horizontal 55°, Vertical 29°
VPort P06HC-1V80M Series: f=8.0 mm, F1.6, Diagonal 45°, Horizontal 40°, Vertical 22°

Color: 0.2 lux, at F1.2 (Gain High, 50 IRE, 1/30 sec)

Internal

ATW/AWB

Auto (1/30 to 1/25000 sec)

Maximum 50 dB (AGC off; DNR on)

Built-in DNR

110 dB

Automatic, 50 Hz, 60 Hz modes

Flip, Mirror, and 180° rotation

Manual tuning with saturation, sharpness, and contrast

2X, 4X, 8X, 16X, 32X, 64X

High/Medium/Low

H.264 (ISO/IEC 14496-10) or MJPEG

via Ethernet

3 independent H.264 or MJPEG video streams

Read more

DynaStream™ support for changing the video frame rate automatically
CBR Pro™ for good image quality in limited bandwidth transmissions
3 privacy mask areas provided
Adjustable image size and quality
Timestamp and text overlay
OSD (On Screen Display) position adjustable
Maximum of 5 simultaneous unicast connections, 50 multicast clients

ONVIF Profile S

Camera tampering detection

3 independently configurable areas

Daily repeat timing schedule

JPEG snapshots for pre/trigger/post alarm images

HTTP event servers for setting customized alarm actions

Automatic transfer of stored images via FTP as event-triggered actions

1 GB

Windows 7 or above

Internet Explorer 9.x or above

DirectX 9.0C or above

Metal

60 x 60 x 74.6 mm (2.36 x 2.36 x 2.94 in)

300 g (0.66 lb)

Flush mounting

-CT models: PCB conformal coating

-40 to 55°C (-40 to 131°F)

-40 to 85°C (-40 to 185°F)

5 to 95% (non-condensing)

IEC 60529, IP30 (provided screws are used to fill the camera housing screw holes)

2000 m

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m
IEC 61000-4-4 EFT: Signal: 2 kV
IEC 61000-4-5 Surge: Signal: 1 kV
IEC 61000-4-6 CS: 10 V
IEC 61000-4-8 PFMF

IEC 60068-2-31

EN 45545-2

UL 62368-1

IEC 60068-2-27, IEC 61373, EN 50155

IEC 60068-2-64, IEC 61373, EN 50155

EN 50155 (complies with a portion of EN 50155 specifications)

692,847 hrs

IEC 62380

5 years

See www.moxa.com/tw/warranty
