SDXC

4

+13 to +30 V for state 1
-30 to +1 V for state 0
Max. input current: 8 mA

2

Resistive load: 1 A @ 24 VDC

Terminal block

2

TCP/IP
IPv4/IPv6
UDP
HTTP
RTP/RTSP
ARP
UPnP
FTP
TFTP
NTP Client
DNS
QoS
IGMP v3
ICMP
SNMPv1/v2c/v3
Modbus TCP
HTTPS
802.1X
NTCIP

User-level password protection

IP address

802.1X

HTTPS
SSH

STAT: Indicates if system is booted up properly or not
Power 1: Power 1 on/off
Power 2: Power 2 on/off
FAULT: Can be configured to correspond to system alarm, power failure, or disconnected network
Video: Video input signal
PTZ: Indicates if PTZ or COM port data has been transmitted
SD: Indicates if SD card was mounted successfully
Network: 10 Mbps or 100 Mbps

1, RS-232 or RS-422/485 port, terminal block connector, 115.2 kbps

1, RS-232 or RS-485 port, DB9 male connector, 115.2 kbps

1 RS-232 port, 10-pin RJ45 (115200, n, 8, 1)

2

Redundant dual inputs

12 to 32 VDC, 18 to 30 VAC

1 A @ 12 VDC
0.3 A @ 32 VDC
0.92 A @ 18 VAC
0.56 A @ 30 VAC

2-pin terminal block

H.264 (ISO/IEC 14496-10) or MJPEG

4, BNC connector (1.0 Vpp, 75 ohm)

via Ethernet

2 independent H.264 or MJPEG video streams
1 quad (4-channel images) stream

Auto-sensing or manual

Read more

DynaStream™ support for changing the video frame rate automatically
CBR Pro™ for good image quality in limited bandwidth transmissions
Adjustable image size and quality
Timestamp and text overlay
OSD (On Screen Display) position adjustable
Maximum of 10 simultaneous unicast connections, 50 multicast clients
Image tuning control: brightness, contrast, saturation, sharpness, noise reduction

1 Line-in or MIC-in with 3.5 mm phone jack

1 Line-out, with 3.5 mm phone jack

Mono, PCM (G.711)

ONVIF Profile S

Via PTZ port or COM port

Pan, tilt, zoom, focus, move speed, preset position (max. 128 positions)

Driver upload supported

Pelco D, Pelco P, Custom Camera

Camera tampering detection

3 independently configurable areas

Daily repeat timing schedule

JPEG snapshots for pre/trigger/post alarm images

HTTP event servers for setting customized alarm actions

Automatic transfer of stored images via FTP as event-triggered actions

50 MB video buffer for JPEG snapshot images

Event recordings stored on the SD card

1 GB

Windows 7 or above

Internet Explorer 9.x or above

DirectX 9.0C or above

Metal

80.2 x 135 x 105 mm (3.16 x 5.31 x 4.13 in)

1130 g (2.49 lb)

DIN-rail mounting
Wall mounting (with optional kit)

Standard Models: -25 to 60°C (-13 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)

-40 to 85°C (-40 to 185°F)

5 to 95% (non-condensing)

2000 m

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV
IEC 61000-4-6 CS: 10 V
IEC 61000-4-8 PFMF

IEC 60068-2-31

UL 60950-1

IEC 60068-2-27

IEC 60068-2-6

827,831 hrs

Telcordia SR332

5 years

See www.moxa.com/tw/warranty
