100Base-Fx ports (single-mode/multi-mode ST connector)

Read more

Note: The “typical distance” of a specific fiber transceiver can be computer using Link budget (dB) > Dispersion penalty (dB) + Total link loss (dB).

2 kV (built-in)

1

CAN_L, CAN_H, CAN Signal GND

N/A, 120 ohms (by DIP)

CAN 2.0A, CAN 2.0B, CAN FD, compatible with ISO 11898 standard (DIP switch to select CAN 2.0/CAN FD setting)

1

ICF-1171I-S-ST/ ICF-1171I-S-ST-T: Single-mode ST connector
ICF-1171I-M-ST/ ICF-1171I-M-ST-T: Multi-mode ST connector

Single-mode, typical distance 40 km
Multi-mode, typical distance 2 km

188.5 mA (max.)

12 to 48 VDC

2

Terminal block

Resistive load: 1 A @ 30 VDC

NC, COM, NO

Metal

IP30

30.3 x 70 x 115 mm (1.19 x 2.76 x 4.53 in)

294 g (0.65 lb)

DIN-rail mounting, Wall mounting (with optional kit)

ICF-1171I-S-ST, ICF-1171I-M-ST: 0 to 60°C (32 to 140°F)
ICF-1171I-S-ST-T, ICF-1171I-M-ST-T: -40 to 75°C (-40 to 167°F)

-40 to 85°C (-40 to 185°F)

5 to 95% (non-condensing)

EN 55032/35

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
IEC 61000-4-4 EFT: Power: 4 kV; Signal: 2 kV
IEC 61000-4-5 Surge: Power: 2 kV, Signal: 2 kV
IEC 61000-4-6 CS: 150 kHz to 80 MHz: 10 V/m; Signal: 10 V/m
IEC 61000-4-8 PFMF

KC

UL 62368-1, EN 62368-1

IEC 60068-2-6

2,412,885 hrs

Telcordia (Bellcore), GB

5 years
