TRC-190-AC: 110 to 240 VAC
TRC-190-DC-48: 48 VDC
Redundant dual inputs, Redundant dual inputs

2

Supported

TRC-190-AC: 1.5 A @ 100 to 240 VAC
TRC-190-DC-48: 3.2 A @ 36 to 53 VDC

440 x 260 x 88 mm (17.32 x 10.24 x 3.46 in)

19-inch rack mounting

IP30

5200 g (11.4 lb)

5 to 95% (non-condensing)

0 to 60°C (32 to 140°F)

-20 to 75°C (-4 to 167°F)

EN 55032/35

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV
IEC 61000-4-5 Surge: Power: 2 kV(AC), 1 kV(DC)
IEC 61000-4-6 CS: 150 kHz to 80 MHz: 3 V/m; Signal: 3 V/m
IEC 61000-4-8 PFMF

IEC 60068-2-1
IEC 60068-2-2
IEC 60068-2-3

IEC 62368-1, UL 62368-1

IEC 60068-2-6

1,055,112 hrs

Telcordia (Bellcore), GB

5 years

See www.moxa.com/tw/warranty
