50 bps to 921.6 kbps (supports non-standard baudrates)

Terminal block

TCC-100I/100I-T: 2 kV (-I model)

2

1 kilo-ohm, 150 kilo-ohms

ADDC® (automatic data direction control)

RS-232, RS-422, RS-485

N/A, 120 ohms, 120 kilo-ohms

TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND

Tx+, Tx-, Rx+, Rx-, GND

Tx+, Tx-, Rx+, Rx-, GND

Data+, Data-, GND

TCC-100/100-T: 50 to 85 mA @ 12 to 48 VDC
TCC-100I/100I-T: 150 mA @ 12 to 48 VDC

12 to 48 VDC

1

Supported

Terminal block (for DC models)

TCC-100/100-T: 50 to 85 mA @ 12 to 48 VDC
TCC-100I/100I-T: 150 mA @ 12 to 48 VDC

Metal

67 x 100.4 x 22 mm (2.64 x 3.93 x 0.87 in)

IP30

148 g (0.33 lb)

DIN-rail mounting (with optional kit), Wall mounting

Standard Models: -20 to 60°C (-4 to 140°F)
Wide Temp. Models: -40 to 85°C (-40 to 185°F)

-40 to 85°C (-40 to 185°F)

5 to 95% (non-condensing)

EN 55032/24

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV
IEC 61000-4-5 Surge: Power: 1 kV
IEC 61000-4-6 CS: 150 kHz to 80 MHz: 3 V/m; Signal: 3 V/m
IEC 61000-4-8 PFMF

IEC 60068-2-1
IEC 60068-2-2
IEC 60068-2-3

EN 60950-1, IEC 60950-1

IEC 60068-2-6

3,017,857 hrs

Telcordia (Bellcore), GB

5 years

See www.moxa.com/tw/warranty
