Terminal block

2

RS-422, RS-485

50 bps to 921.6 kbps (supports non-standard baudrates)

TCC-120I: 2 kV

1 kilo-ohm, 150 kilo-ohms

ADDC® (automatic data direction control)

N/A, 120 ohms, 120 kilo-ohms

Tx+, Tx-, Rx+, Rx-, GND

Tx+, Tx-, Rx+, Rx-, GND

Data+, Data-, GND

TCC-120: 65 mA @ 12 VDC
TCC-120I: 180 mA @ 12 VDC

12 to 48 VDC

1

Supported

Terminal block (for DC models)

TCC-120: 65 mA @ 12 VDC
TCC-120I: 180 mA @ 12 VDC

Metal

IP30

67 x 100.4 x 22 mm (2.64 x 3.93 x 0.87 in)

148 g (0.33 lb)

DIN-rail mounting (with optional kit), Wall mounting

Standard Models: -20 to 60°C (-4 to 140°F)

-40 to 85°C (-40 to 185°F)

5 to 95% (non-condensing)

EN 55032/24

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV
IEC 61000-4-5 Surge: Power: 1 kV
IEC 61000-4-6 CS: 150 kHz to 80 MHz: 3 V/m; Signal: 3 V/m
IEC 61000-4-8 PFMF

IEC 60068-2-1
IEC 60068-2-2
IEC 60068-2-3

EN 60950-1, IEC 60950-1

IEC 60068-2-6

1,949,025 hrs

Telcordia (Bellcore), GB

5 years

See www.moxa.com/tw/warranty
