USB 1.1/2.0 compliant
USB 3.2 Gen 1

5 Gbps

UFP: type B
DFP: type A

8 (UFP: 1, DFP 7) for UPort 207A
5 (UFP: 1, DFP 4) for UPort 204A

No. of power inputs: 1, 12 VDC

Power jack

UPort 207A: 4.5 A @ 12 VDC
UPort 204A: 2.65 A @ 12 VDC

Supported

Port 1: 900 / 1500 mA @ 5 VDC (BC 1.2 compatible)
Rest of ports: 900 mA @ 5 VDC

Metal

UPort 207A: 80 x 27 x 140 mm (3.15 x 1.06 x 5.51 in)
UPort 204A: 85 x 27 x 100 mm (3.35 x 1.06 x 3.94 in)

UPort 207A: 273 g (0.60 lb)
UPort 204A: 208 g (0.46 lb)

DIN-rail mounting (with optional kit), Wall mounting (with optional kit)

0 to 60°C (32 to 140°F)

-20 to 75°C (-4 to 167°F)

5 to 95% (non-condensing)

EN 55032/35

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m
IEC 61000-4-4 EFT: Power: 1 kV
IEC 61000-4-5 Surge: Power: 1 kV
IEC 61000-4-6 CS: 150 kHz to 80 MHz: 10 V/m
IEC 61000-4-8 PFMF

EN 62368-1, UL 62368-1, KC

IEC 60068-2-1

IEC 60068-2-34

RoHS, CRoHS, WEEE

Telcordia (Bellcore), GB

UPort 207A: 1,957,123 hours
UPort 204A: 2,678,801 hours
