USB 3.2 Gen 1
USB 1.1/2.0 compliant

5 Gbps

UFP: type B
DFP: type A

8 (UFP: 1, DFP 7) for UPort 407A models
5 (UFP: 1, DFP 4) for UPort 404A models

12 to 48 VDC
No. of power inputs: 2

Power jack
3-pin terminal block

Supported

UPort 407A Models: 4.75A @ 12 VDC
UPort 404A Models: 2.8A @ 12 VDC

Port 1: 900 mA / 1500 mA @ 5 VDC, BC 1.2 compliant
Rest of ports: 900 mA @ 5 VDC

Metal

UPort 407A models: 80 x 27 x 140 mm (3.15 x 1.06 x 5.51 in)
UPort 404A models: 85 x 27 x 100 mm (3.35 x 1.06 x 3.94 in)

UPort 407A models: 350 g (0.77 lb)
UPort 404A models: 264 g (0.58 lb)

Wall mounting (with optional kit)
DIN-rail mounting (with optional kit)

Standard Models: 0 to 60°C (32 to 140°F)
Wide Temp. Models: -40 to 85°C (-40 to 185°F)

Standard Models: -20 to 75°C (-4 to 167°F)
Wide Temp.Models: -40 to 85°C (-40 to 185°F)

5 to 95% (non-condensing)

EN 55032/35

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m
IEC 61000-4-4 EFT: Power: 2 kV
IEC 61000-4-5 Surge: Power: 2 kV
IEC 61000-4-6 CS: 150 kHz to 80 MHz: 10 V/m
IEC 61000-4-8 PFMF

EN 62368-1
UL 62368-1
KC

IEC 60068-2-1

IEC 60068-2-34

RoHS, CRoHS, WEEE

Telcordia (Bellcore), GB

UPort 407A Models: 1,467,922 hours (minimum)
UPort 404A Models: 2,107,973 hours (minimum)
