12 Mbps, 480 Mbps

USB Type B

USB 1.1/2.0 compliant

UPort 404 Series: 4
UPort 407 Series: 7

UPort 404 Series: 1.3 A @ 12 VDC
UPort 407 Series: 2.3 A @ 12 VDC

12 to 40 VDC

Aluminum

UPort 404 Series: 80 x 35 x 130 mm (3.15 x 1.38 x 5.12 in)
UPort 407 Series: 100 x 35 x 192 mm (3.94 x 1.38 x 7.56 in)

Packaged:
UPort 404 Series: 855 g (1.88 lb)
UPort 407 Series: 965 g (2.13 lb)

Product Only:
UPort 404 Series: 850 g (1.87 lb)
UPort 407 Series: 950 g (2.1 lb)

Wall mounting, DIN-rail mounting (optional)

Standard Models: 0 to 60°C (32 to 140°F)
Wide Temp. Models: -40 to 85°C (-40 to 185°F)

Standard Models: -20 to 75°C (-4 to 167°F)
Wide Temp. Models: -40 to 85°C (-40 to 185°F)

EN 55032/24

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m
IEC 61000-4-4 EFT: Power: 2 kV
IEC 61000-4-5 Surge: Power: 1 kV
IEC 61000-4-6 CS: 150 kHz to 80 MHz: 10 V/m; Signal: 0 V/m
IEC 61000-4-8 PFMF

IEC 60068-2-1

UL 508

IEC 60068-2-34

RoHS, CRoHS, WEEE

UPort 404 Series: 1,490,340 hrs
UPort 407 Series: 1,111,361 hrs

Telcordia (Bellcore), GB

5 years

See www.moxa.com/tw/warranty
