1 relay output with current carrying capacity of 1 A @ 24 VDC

8

2

2 modular slots for any 8-port or 6-port Interface Modules with 10/100BaseT(X), 100BaseFX (SC/ST connector), or 100Base SFP 如需快速乙太網路模組產品資訊，請參閱 IM-6700A 產品規格書。

IEEE 802.1D-2004 for Spanning Tree Protocol
IEEE 802.1p for Class of Service
IEEE 802.1Q for VLAN Tagging
IEEE 802.1s for Multiple Spanning Tree Protocol
IEEE 802.1w for Rapid Spanning Tree Protocol
IEEE 802.1X for authentication
IEEE 802.3 for 10BaseT
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3ad for Port Trunk with LACP
IEEE 802.3u for 100BaseT(X) and 100BaseFX
IEEE 802.3x for flow control
IEEE 802.3z for 1000BaseSX/LX/LHX/ZX

Back Pressure Flow Control
BOOTP
DDM
DHCP Option 66/67/82
DHCP Server/Client
Flow control
IPv4/IPv6
LLDP
Port Mirror
RARP
RMON
SCP
SMTP
SNMP Inform
SNMPv1/v2c/v3
Syslog
Telnet
TFTP

802.1Q
BPDU Filter
BPDU Guard
GMRP
GVRP
IGMP v1/v2/v3

Link Aggregation
MRP
MSTP
RSTP
STP
Turbo Chain
Turbo Ring v1/v2
V-ON

Access control list
Broadcast storm protection
HTTPS/SSL
MAB authentication
NTP authentication
Port Lock
RADIUS
SSH
TACACS+

SNTP

EtherNet/IP
Modbus TCP
PROFINET

Ethernet-like MIB
MIB-II
P-BRIDGE MIB
Q-BRIDGE MIB
RMON MIB Groups 1, 2, 3, 9
RSTP MIB

2048

9.6 KB

16 K

64

12 Mbits

4

VID 1 to 4094

USB Type A

USB-serial console (Type B connector)

IKS-6726A-2GTXSFP-24-T: 24 VDC
IKS-6726A-2GTXSFP-24-24-T: 24 VDC (redundant dual inputs)
IKS-6726A-2GTXSFP-48-T: 48 VDC
IKS-6726A-2GTXSFP-48-48-T: 48 VDC (redundant dual inputs)
IKS-6726A-2GTXSFP-HV-T: 110/220 VAC
IKS-6726A-2GTXSFP-HV-HV-T: 110/220 VAC (redundant dual inputs)

IKS-6726A-2GTXSFP-24-T: 18 to 36 VDC
IKS-6726A-2GTXSFP-24-24-T: 18 to 36 VDC
IKS-6726A-2GTXSFP-48-T: 36 to 72 VDC
IKS-6726A-2GTXSFP-48-48-T: 36 to 72 VDC
IKS-6726A-2GTXSFP-HV-T: 85 to 264 VAC
IKS-6726A-2GTXSFP-HV-HV-T: 85 to 264 VAC

1.1/0.6 A @ 24/48 VDC
0.46/0.31 A @ 110/220 VAC
Note: These are the input current ratings for the device with the maximum number of modules installed.

26.4/28.8 W @ 24/48 VDC
29.28/31.92 W @ 110/220 VAC
Note: These are the power consumption ratings for the device with the maximum number of modules installed.

Supported

Supported

IP30

440 x 44 x 280 mm (17.32 x 1.37 x 11.02 in)

4100 g (9.05 lb)

Rack mounting

-40 to 75°C (-40 to 167°F)

-40 to 85°C (-40 to 185°F)

5 to 95% (non-condensing)

EN 60950-1
UL 60950-1

EN 55032/24

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV
IEC 61000-4-6 CS: 10 V
IEC 61000-4-8 PFMF

EN 50121-4

ABS
DNV
LR
NK

IEC 60068-2-32

IEC 60068-2-27

IEC 60068-2-6

IKS-6726A-2GTXSFP-24-T: 851,519 hrs
IKS-6726A-2GTXSFP-24-24-T: 851,519 hrs
IKS-6726A-2GTXSFP-48-T: 852,899 hrs
IKS-6726A-2GTXSFP-48-48-T: 852,899 hrs
IKS-6726A-2GTXSFP-HV-T: 942,524 hrs
IKS-6726A-2GTXSFP-HV-HV-T: 932,847 hrs

Telcordia (Bellcore), GB

5 years

See www.moxa.com/tw/warranty
