8

Full/Half duplex mode
Auto MDI/MDI-X connection
Auto negotiation speed

IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X) and 100BaseFX
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.1p for Class of Service
IEEE 802.3x for flow control

Store and Forward

4 K

1.5 Mbits

Quality of Service (QoS), Broadcast Storm Protection (BSP)

1 removable 2-contact terminal block(s)

0.33 A (max.)

12/24/48 VDC

9.6 to 60 VDC

Supported

Supported

DIN-rail mounting
Wall mounting (with optional kit)

180 g (0.4 lb)

Metal

36 x 81 x 65 mm (1.42 x 3.19 x 2.56 in)

Standard Models: -10 to 60°C (14 to 140°F)
Wide Temp. Models (-T): -40 to 75°C (-40 to 167°F)

5 to 95% (non-condensing)

-40 to 85°C (-40 to 185°F)

UL 61010-2-201
EN 62368-1 (LVD)

EN 55032/35
EN 61000-6-2/-6-4

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m
IEC 61000-4-4 EFT: Power: 1 kV; Signal: 1 kV
IEC 61000-4-5 Surge: Power: 1 kV; Signal: 1 kV
IEC 61000-4-6 CS: 10 V
IEC 61000-4-8 PFMF

IEC 60068-2-27

IEC 60068-2-6

IEC 60068-2-32

3,404,784 hrs

Telcordia (Bellcore), GB

5 years

See www.moxa.com/tw/warranty
