MOXA

10 Gigabit Ethernet SFP+ Modules

Moxa's small form-factor pluggable transceiver (SFP) Ethernet fiber modules for 10 Gigabit provide coverage across a wide range of communication distances.

SFP-10GSRLC-T
SFP-10G Series

SFP+ module with 1 10GBase-SR port, LC connector for 33m/82m/300m/400m transmission, -40 to 85°C operating temperature

Ethernet Interface

  • Connectors

    • Duplex LC connector

  • Optical Fiber

    • 10G Ethernet SFP
      SFP-SR SFP-LR SFP-ER SFP-ZR
      Transceiver Type Multi-Mode Single-mode Single-mode Single-mode
      Fiber Cable Type OM1 OM2 OM3 OM4 G.652 G.652 G.652
      Typical Distance 33 m 82 m 300 m 400 m 10 km 40 km 80 km
      Wavelength Typical (nm) 850 1310 1550 1550
      TX Range (nm) 840 to 860 1260 to 1355 1530 to 1565 1530 to 1565
      RX Range (nm) 840 to 860 1260 to 1355 1530 to 1565 1530 to 1565
      Optical Power TX Range (dBm) -5 to -1 -8.2 to +0.5 -1 to +2 0 to +4
      RX Range (dBm) -9.9 to +0.5 -14.4 to +0.5 -15.8 to -1 -23 to -7
      Link Budget (dB) 6.8 7.4 15 23
      Dispersion Penalty (dB) 3.9 1 3 3
      Note: When connecting the SFP-ER or SFP-ZR, we recommend using an attenuator to prevent damage caused by excessive optical power.

  • Optical Fiber

    • Typical Distance: To reach the typical distance of specified fiber transceiver, please refer to formula: Link budget(dB) > dispersion penalty(dB) + total link loss(dB)
Environmental Limits

  • Operating Temperature

    • -40 to 85°C (-40 to 185°F)
      Note: When using the SFP-10GZRLC-T with the ICS-G7526A/G7528A/G7826A/G7828A and the MDS-G4000-4XGS/MDS-G4000-L3-4XGS Series, the maximum temperature is -10 to 60°C (14 to 140°F).

  • Storage Temperature (package included)

    • -40 to 85°C (-40 to 185°F)

  • Ambient Relative Humidity

    • 5 to 95% (non-condensing)
Standards and Certifications

  • Safety

    • UL 62368-1
      IEC 62368-1
      IEC 60825-1

  • EMC

    • EN 55032/35

  • EMI

    • FCC 15B Test Report
      ICES-003: 2020 Issue 7

  • EMS

    • IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
      IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
      IEC 61000-4-4 EFT: Power: 1 kV(AC), 0.5 kV(DC); Signal: 0.5 kV
      IEC 61000-4-5 Surge: Power: 1 kV/2 kV(AC), 0.5 kV(DC); Signal: 1 kV
      IEC 61000-4-6 CS: 0.15 MHz to 10 MHz: 3 V, 10 MHz to 30 MHz: 3 to 1 V, 30 MHz to 80 MHz: 1V.
      IEC 61000-4-8 PFMF: 1 A/m at 50 Hz
      IEC 61000-4-11: Voltage Dips & Interruption
Warranty
