Home Products Industrial Computing System Software Moxa DLM (on-premises) LIC-DLM-ONPREM-NEW-XN-SR
MOXA

System Software

To accelerate project development and speed up your time to market, Moxa provides programmers with a variety of user-friendly software tools, making it easy to develop customized data acquisition, wireless/cellular communication, and remote device management applications.



For more information, visit our Moxa Industrial Linux portal site.

LIC-DLM-ONPREM-NEW-XN-SR
Moxa DLM (on-premises)

DLM on-premises perpetual license (1 node)

Hardware Requirements

  • CPU

    • Minimum Requirement:
      4 vCPU (Intel® Pentium® G4600) tested on VMware
      with 1,000 devices
      Recommended:
      8 vCPU (Intel® Xeon® Silver 4310) tested on VMware
      with 3,000 devices

  • RAM

    • 4 GB (1,000 devices)
      16 GB (3,000 devices)

  • Hardware Disk Space

    • 100 GB (HDD/SSD, 1,000 devices)
      500 GB (HDD/SSD, 3,000 devices)

  • OS

    • Ubuntu 20.04 LTS
      Ubuntu 22.04 LTS (64-bit)
System Requirements

  • Eligible Devices

    • UC-1200A / UC-2200A (MIL 3.4.1, image v1.4 or later)
      UC-3400A (MIL 3.4.1, image v1.2 or later)
      UC-4400A (MIL 3.4.1, image v1.3 or later)
      UC-8200 (MIL 3.4.1, image v1.5 or later)
      UC-8600A Series (MIL 4.0, image v1.0 or later)

  • Servers

    • SMTP email server:
      Supports STARTTLS (optional) or unencrypted SMTP f
      for sending event notifications
      File server (optional):
      External HTTPS file servers are recommended for hosting large OTA packages

Network Requirements

  • Ports

    • TCP 443: DLM web interface (HTTPS)
      TCP 8883: Secure MQTT from UC devices (TLS-RSA)
      TCP 50001 to 50010: Remote Connect (SSH over VPN, up to 10 sessions)

  • Internet

    • Required for installing DLM and accessing external package repositories

  • Interface Management

    • Cellular/Wi-Fi interfaces on the devices must be managed by Moxa Connection Manager (MCM) for full functionality

  • Time Synchronization

    • NTP
      DLM server and devices must be able to reach an NTP server to enable accurate time synchronization for TLS, logs, and tokens

  • Domain Name

    • FQDN
      Recommended to ensure certificate and login stability.
      At a minimum, the DLM server must have a static IP address
