SDXC

1

+13 to +30 V for state 1
-30 to +1 V for state 0
Max. input current: 8 mA

5-pin A-coded male M12 connector with 20 cm cable

1

IEEE 802.3af for PoE

TCP/IP, IPv4/IPv6, UDP, HTTP, RTP/RTSP, ARP, UPnP, FTP, TFTP, SMTP, NTP Client, DNS, DDNS, QoS, IGMP v3, ICMP, SNMPv1/v2c/v3, DHCP Opt66/67, HTTPS

User-level password protection

IP address

HTTPS

1

PoE (IEEE 802.3af)

0.26 A @ 48 VDC

1/3-in 1080P progressive scan CMOS

VPort P16-2MR36M Series: f=3.6mm, F1.6, Diagonal 99°, Horizontal 70°, Vertical 39°
VPort P16-2MR42M Series: f=4.2mm, F1.6, Diagonal 82°, Horizontal 62°, Vertical 34°
VPort P16-2MR60M Series: f=6.0mm, F1.8, Diagonal 62°, Horizontal 43°, Vertical 24°
VPort P16-2MR80M Series: f=8.0mm, F1.6, Diagonal 42°, Horizontal 33°, Vertical 17°

Color: 0.2 lux, at F1.2 (Gain High, 50 IRE, 1/30 sec)
B/W: 0.05 lux, at F1.2 (Gain High, 50 IRE, 1/30 sec)
Note: 0 lux if IR illuminator is on

Pan 350°, Tilt 65° (controlled manually)

Auto/Color/BW; ICR control

Internal

ATW/AWB

Auto, Fixed (1/30 to 1/25000 sec)

Maximum 50 dB (AGC off; DNR on)

Auto (light sensor control) or DI control

IR LED illuminators, 5-meter (max.) effective distance; On/Off controlled manually (night mode) or by the light sensor

Built-in 2D/3D DNR

100 dB

2X, 4X, 8X, 16X

Automatic, 50 Hz, 60 Hz modes

Flip, Mirror, 90°, 180°, 270° rotation

Manual tuning with saturation, sharpness, and contrast

H.264 (ISO/IEC 14496-10) or MJPEG

via Ethernet

4 independent H.264 or MJPEG video streams

Read more

DynaStream™ support for changing the video frame rate automatically
CBR Pro™ for good image quality in limited bandwidth transmissions
3 privacy mask areas provided
Adjustable image size and quality
Timestamp and text overlay
OSD (On Screen Display) position adjustable
Maximum of 5 simultaneous unicast connections, 50 multicast clients

Mono, PCM (G.711)
AAC

1 x built-in microphone

ONVIF Profile S

Camera tampering detection

3 independently configurable areas

Built-in G sensor

Daily repeat timing schedule

JPEG snapshots for pre/trigger/post alarm images

HTTP event servers for setting customized alarm actions

Automatic transfer of stored images via email or FTP as event-triggered actions

50 MB video buffer for JPEG snapshot images

Event recordings stored on the SD card

2 GB

Windows 7 or above

Internet Explorer 9.x or above

DirectX 9.0C or above

IP66 rain and dust protection
Metal housing, PC dome cover
IK8 vandal resistant protection

125 x 125 x 120.7 mm (4.92 x 4.92 x 4.8 in)

890 g (1.96 lb)

Panel mounting

-CT models: PCB conformal coating

Standard Models: -25 to 55°C (-13 to 131°F)
Wide Temp. Models: -40 to 70°C (-40 to 158°F)

-40 to 85°C (-40 to 185°F)

5 to 95% (non-condensing)

IEC 60529, IP66

ASTM-B117

EN 62262, IK8

2000 m

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV
IEC 61000-4-6 CS: 10 V
IEC 61000-4-8 PFMF

IEC 60068-2-31

EN 45545-2

UL 60950-1

IEC 60068-2-27, IEC 61373, EN 50155

IEC 60068-2-64, IEC 61373, EN 50155

EN 50155 (complies with a portion of EN 50155 specifications)

997,474 hrs

Telcordia SR332

5 years
Note: Limited warranty on moving parts; see Moxa's online warranty policy for details.

See www.moxa.com/tw/warranty
