TAP-M310R 系列

Wi-Fi 6 (802.11ax) 鐵路列車對地 IP67 無線 AP/用戶端

moxa-tap-m310r-series-image-(1).jpg | Moxa

moxa-tap-m310r-series-image-1-(1).jpg | Moxa

moxa-tap-m310r-series-image-2-(1).jpg | Moxa

moxa-tap-m310r-series-image-3-(1).jpg | Moxa

moxa-tap-m310r-series-image-4-(1).jpg | Moxa

moxa-tap-m310r-series-image-5-(1).jpg | Moxa

特色與優點

具整合式交換器連接埠與 AC 或 DC 電源輸入的彈性型號選擇
內建天線分離器以最佳化軌旁部署
內建 2.4 GHz 和 5 GHz 帶通濾波器，可實現更可靠的無線連接
實現低於 50 毫秒且以控制器為基礎的 Turbo Roaming 快速漫遊，達成無縫列車對地通訊

認證

您可在 My Moxa 查看已追蹤產品的更新資訊

聯絡銷售顧問

簡介

TAP-M310R 系列 Wi-Fi 6 (802.11ax) 鐵路列車對地 IP67 等級無線 AP/用戶端專為 CBTC、CCTV 與 BBRS 通訊所設計，支援切換時間低於 50 毫秒的無縫以控制器為基礎的 Turbo Roaming 快速漫遊。TAP-M310R 系列提供多種配置，包括 AC 或 DC 電源輸入以及整合式交換器連接埠，可實現更彈性的部署，以滿足不同車載與軌旁應用的需求。TAP-M310R 系列內建帶通濾波器以減少干擾，並具備 Moxa 的 Turbo Chain 技術，以提供可靠的 LAN 通訊。

下載產品資料表
列印此頁
儲存至 My Moxa

您可管理並分享您儲存在 My Moxa 中的頁面清單

WLAN Standards

2.4 GHz: 802.11b/g/n/ax with 1024 QAM support, 20/40 MHz
5 GHz: 802.11a/n/ac/ax with 1024 QAM support, 20/40/80 MHz
Frequency Band for US (20 MHz operating channels)

TAP-M310R-US models only:
2.412 to 2.462 GHz (11 channels)
5.180 to 5.240 GHz (4 channels)
5.745 to 5.825 GHz (5 channels)
Frequency Band for EU (20 MHz operating channels)

TAP-M310R-EU models only:
2.412 to 2.472 GHz (13 channels)
5.180 to 5.240 GHz (4 channels)
5.745 to 5.825 GHz (5 channels)
Wireless Security

SSID broadcast enable/disable
WPA2/WPA3 Personal (AES)
WPA2/WPA3 Enterprise (IEEE 802.1X/RADIUS, AES)
Transmission Rate

802.11b: 1 to 11 Mbps
802.11a/g: 6 to 54 Mbps
802.11n: 6.5 to 300 Mbps
802.11ac: up to 540 Mbps
802.11ax: 5 GHz up to 1201 Mbps, 2.4 GHz up to 576 Mbps
Transmitter Power for 802.11a

TAP-M310R-NPS-1R and -1P1R models:
22±1.5 dBm @ 6 Mbps 20 MHz
22±1.5 dBm @ 9 Mbps 20 MHz
22±1.5 dBm @ 12 Mbps 20 MHz
22±1.5 dBm @ 18 Mbps 20 MHz
20±1.5 dBm @ 24 Mbps 20 MHz
19.5±1.5 dBm @ 36 Mbps 20 MHz
19±1.5 dBm @ 48 Mbps 20 MHz
19±1.5 dBm @ 54 Mbps 20 MHz

TAP-M310R-1P1R1S and -1P2R1S models:
18±1.5 dBm @ 6 Mbps 20 MHz
18±1.5 dBm @ 9 Mbps 20 MHz
18±1.5 dBm @ 12 Mbps 20 MHz
18±1.5 dBm @ 18 Mbps 20 MHz
17±1.5 dBm @ 24 Mbps 20 MHz
17±1.5 dBm @ 36 Mbps 20 MHz
16±1.5 dBm @ 48 Mbps 20 MHz
15.5±1.5 dBm @ 54 Mbps 20 MHz
Transmitter Power for 802.11n (5 GHz)

TAP-M310R-NPS-1R and -1P1R models:
22±1.5 dBm @ MCS0 20 MHz
22±1.5 dBm @ MCS1 20 MHz
21.5±1.5 dBm @ MCS2 20 MHz
21.5±1.5 dBm @ MCS3 20 MHz
19.5±1.5 dBm @ MCS4 20 MHz
19±1.5 dBm @ MCS5 20 MHz
19±1.5 dBm @ MCS6 20 MHz
18.5±1.5 dBm @ MCS7 20 MHz
22±1.5 dBm @ MCS8 20 MHz
22±1.5 dBm @ MCS9 20 MHz
21.5±1.5 dBm @ MCS10 20 MHz
21.5±1.5 dBm @ MCS11 20 MHz
20.5±1.5 dBm @ MCS12 20 MHz
19.5±1.5 dBm @ MCS13 20 MHz
19.5±1.5 dBm @ MCS14 20 MHz
19±1.5 dBm @ MCS15 20 MHz
22±1.5 dBm @ MCS0 40 MHz
22±1.5 dBm @ MCS1 40 MHz
22±1.5 dBm @ MCS2 40 MHz
21.5±1.5 dBm @ MCS3 40 MHz
21±1.5 dBm @ MCS4 40 MHz
20±1.5 dBm @ MCS5 40 MHz
20±1.5 dBm @ MCS6 40 MHz
19.5±1.5 dBm @ MCS7 40 MHz
22±1.5 dBm @ MCS8 40 MHz
22±1.5 dBm @ MCS9 40 MHz
21.5±1.5 dBm @ MCS10 40 MHz
21.5±1.5 dBm @ MCS11 40 MHz
20±1.5 dBm @ MCS12 40 MHz
20±1.5 dBm @ MCS13 40 MHz
20±1.5 dBm @ MCS14 40 MHz
20±1.5 dBm @ MCS15 40 MHz

TAP-M310R-1P1R1S and -1P2R1S models:
18.5±1.5 dBm @ MCS0 20 MHz
18.5±1.5 dBm @ MCS1 20 MHz
18.5±1.5 dBm @ MCS2 20 MHz
18±1.5 dBm @ MCS3 20 MHz
17±1.5 dBm @ MCS4 20 MHz
16.5±1.5 dBm @ MCS5 20 MHz
16±1.5 dBm @ MCS6 20 MHz
15.5±1.5 dBm @ MCS7 20 MHz
18.5±1.5 dBm @ MCS8 20 MHz
18.5±1.5 dBm @ MCS9 20 MHz
18.5±1.5 dBm @ MCS10 20 MHz
18±1.5 dBm @ MCS11 20 MHz
17±1.5 dBm @ MCS12 20 MHz
16.5±1.5 dBm @ MCS13 20 MHz
15.5±1.5 dBm @ MCS14 20 MHz
15.5±1.5 dBm @ MCS15 20 MHz
18.5±1.5 dBm @ MCS0 40 MHz
18.5±1.5 dBm @ MCS1 40 MHz
18.5±1.5 dBm @ MCS2 40 MHz
17.5±1.5 dBm @ MCS3 40 MHz
17.5±1.5 dBm @ MCS4 40 MHz
16.5±1.5 dBm @ MCS5 40 MHz
15.5±1.5 dBm @ MCS6 40 MHz
15±1.5 dBm @ MCS7 40 MHz
18±1.5 dBm @ MCS8 40 MHz
18±1.5 dBm @ MCS9 40 MHz
17.5±1.5 dBm @ MCS10 40 MHz
17±1.5 dBm @ MCS11 40 MHz
17±1.5 dBm @ MCS12 40 MHz
16.5±1.5 dBm @ MCS13 40 MHz
15.5±1.5 dBm @ MCS14 40 MHz
15±1.5 dBm @ MCS15 40 MHz
Transmitter Power for 802.11ac (5 GHz, Dual Chain)

TAP-M310R-NPS-1R and -1P1R models:
22±1.5 dBm @ MCS0 20 MHz
22±1.5 dBm @ MCS1 20 MHz
21.5±1.5 dBm @ MCS2 20 MHz
21.5±1.5 dBm @ MCS3 20 MHz
20.5±1.5 dBm @ MCS4 20 MHz
20±1.5 dBm @ MCS5 20 MHz
19.5±1.5 dBm @ MCS6 20 MHz
19.5±1.5 dBm @ MCS7 20 MHz
19±1.5 dBm @ MCS8 20 MHz
21.5±1.5 dBm @ MCS0 40 MHz
21.5±1.5 dBm @ MCS1 40 MHz
21±1.5 dBm @ MCS2 40 MHz
20.5±1.5 dBm @ MCS3 40 MHz
20±1.5 dBm @ MCS4 40 MHz
19.5±1.5 dBm @ MCS5 40 MHz
19.5±1.5 dBm @ MCS6 40 MHz
19.5±1.5 dBm @ MCS7 40 MHz
19±1.5 dBm @ MCS8 40 MHz
18.5±1.5 dBm @ MCS9 40 MHz
21±1.5 dBm @ MCS0 80 MHz
21±1.5 dBm @ MCS1 80 MHz
21±1.5 dBm @ MCS2 80 MHz
21±1.5 dBm @ MCS3 80 MHz
20±1.5 dBm @ MCS4 80 MHz
20±1.5 dBm @ MCS5 80 MHz
19±1.5 dBm @ MCS6 80 MHz
19±1.5 dBm @ MCS7 80 MHz
18.5±1.5 dBm @ MCS8 80 MHz
18.5±1.5 dBm @ MCS9 80 MHz

TAP-M310R-1P1R1S and -1P2R1S models:
18±1.5 dBm @ MCS0 20 MHz
18±1.5 dBm @ MCS1 20 MHz
18±1.5 dBm @ MCS2 20 MHz
18±1.5 dBm @ MCS3 20 MHz
17±1.5 dBm @ MCS4 20 MHz
17±1.5 dBm @ MCS5 20 MHz
15.5±1.5 dBm @ MCS6 20 MHz
15±1.5 dBm @ MCS7 20 MHz
14.5±1.5 dBm @ MCS8 20 MHz
18±1.5 dBm @ MCS0 40 MHz
18±1.5 dBm @ MCS1 40 MHz
18±1.5 dBm @ MCS2 40 MHz
18±1.5 dBm @ MCS3 40 MHz
17±1.5 dBm @ MCS4 40 MHz
17±1.5 dBm @ MCS5 40 MHz
15±1.5 dBm @ MCS6 40 MHz
15.5±1.5 dBm @ MCS7 40 MHz
15±1.5 dBm @ MCS8 40 MHz
14.5±1.5 dBm @ MCS9 40 MHz
18±1.5 dBm @ MCS0 80 MHz
18±1.5 dBm @ MCS1 80 MHz
18±1.5 dBm @ MCS2 80 MHz
18±1.5 dBm @ MCS3 80 MHz
17±1.5 dBm @ MCS4 80 MHz
17±1.5 dBm @ MCS5 80 MHz
15.5±1.5 dBm @ MCS6 80 MHz
15±1.5 dBm @ MCS7 80 MHz
14.5±1.5 dBm @ MCS8 80 MHz
14.5±1.5 dBm @ MCS9 80 MHz
Transmitter Power for 802.11ax (5 GHz, Dual Chain)

TAP-M310R-NPS-1R and -1P1R models:
22±1.5 dBm @ MCS0 20 MHz
22±1.5 dBm @ MCS1 20 MHz
21±1.5 dBm @ MCS2 20 MHz
21±1.5 dBm @ MCS3 20 MHz
19±1.5 dBm @ MCS4 20 MHz
19±1.5 dBm @ MCS5 20 MHz
19±1.5 dBm @ MCS6 20 MHz
19±1.5 dBm @ MCS7 20 MHz
19±1.5 dBm @ MCS8 20 MHz
18.5±1.5 dBm @ MCS9 20 MHz
18±1.5 dBm @ MCS10 20 MHz
17.5±1.5 dBm @ MCS11 20 MHz
21.5±1.5 dBm @ MCS0 40 MHz
21.5±1.5 dBm @ MCS1 40 MHz
21±1.5 dBm @ MCS2 40 MHz
21±1.5 dBm @ MCS3 40 MHz
20±1.5 dBm @ MCS4 40 MHz
20±1.5 dBm @ MCS5 40 MHz
19±1.5 dBm @ MCS6 40 MHz
19±1.5 dBm @ MCS7 40 MHz
19±1.5 dBm @ MCS8 40 MHz
18.5±1.5 dBm @ MCS9 40 MHz
18±1.5 dBm @ MCS10 40 MHz
17.5±1.5 dBm @ MCS11 40 MHz
21±1.5 dBm @ MCS0 80 MHz
21±1.5 dBm @ MCS1 80 MHz
21±1.5 dBm @ MCS2 80 MHz
21±1.5 dBm @ MCS3 80 MHz
20±1.5 dBm @ MCS4 80 MHz
20±1.5 dBm @ MCS5 80 MHz
18.5±1.5 dBm @ MCS6 80 MHz
18.5±1.5 dBm @ MCS7 80 MHz
18.5±1.5 dBm @ MCS8 80 MHz
18±1.5 dBm @ MCS9 80 MHz
18±1.5 dBm @ MCS10 80 MHz
17.5±1.5 dBm @ MCS11 80 MHz

TAP-M310R-1P1R1S and -1P2R1S models:
18±1.5 dBm @ MCS0 20 MHz
18±1.5 dBm @ MCS1 20 MHz
18±1.5 dBm @ MCS2 20 MHz
18±1.5 dBm @ MCS3 20 MHz
17±1.5 dBm @ MCS4 20 MHz
17±1.5 dBm @ MCS5 20 MHz
15.5±1.5 dBm @ MCS6 20 MHz
15±1.5 dBm @ MCS7 20 MHz
14.5±1.5 dBm @ MCS8 20 MHz
14±1.5 dBm @ MCS9 20 MHz
13.5±1.5 dBm @ MCS10 20 MHz
13.5±1.5 dBm @ MCS11 20 MHz
18±1.5 dBm @ MCS0 40 MHz
18±1.5 dBm @ MCS1 40 MHz
17.5±1.5 dBm @ MCS2 40 MHz
17.5±1.5 dBm @ MCS3 40 MHz
16.5±1.5 dBm @ MCS4 40 MHz
16.5±1.5 dBm @ MCS5 40 MHz
16±1.5 dBm @ MCS6 40 MHz
15.5±1.5 dBm @ MCS7 40 MHz
14±1.5 dBm @ MCS8 40 MHz
14±1.5 dBm @ MCS9 40 MHz
13.5±1.5 dBm @ MCS10 40 MHz
13.5±1.5 dBm @ MCS11 40 MHz
18±1.5 dBm @ MCS0 80 MHz
18±1.5 dBm @ MCS1 80 MHz
17.5±1.5 dBm @ MCS2 80 MHz
17.5±1.5 dBm @ MCS3 80 MHz
16.5±1.5 dBm @ MCS4 80 MHz
16.5±1.5 dBm @ MCS5 80 MHz
15.5±1.5 dBm @ MCS6 80 MHz
15.5±1.5 dBm @ MCS7 80 MHz
14.5±1.5 dBm @ MCS8 80 MHz
14±1.5 dBm @ MCS9 80 MHz
13.5±1.5 dBm @ MCS10 80 MHz
13.5±1.5 dBm @ MCS11 80 MHz
Transmitter Power for 802.11b

TAP-M310R-NPS-1R and -1P1R models:
27±1.5 dBm @ 1 Mbps
27±1.5 dBm @ 2 Mbps
27±1.5 dBm @ 5.5 Mbps
27±1.5 dBm @ 11 Mbps

TAP-M310R-1P1R1S and -1P2R1S models:
23.5±1.5 dBm @ 1 Mbps
23.5±1.5 dBm @ 2 Mbps
23.5±1.5 dBm @ 5.5 Mbps
23.5±1.5 dBm @ 11 Mbps
Transmitter Power for 802.11g

TAP-M310R-NPS-1R and -1P1R models:
26.5±1.5 dBm @ 6 Mbps
26.5±1.5 dBm @ 9 Mbps
26.5±1.5 dBm @ 12 Mbps
25±1.5 dBm @ 18 Mbps
25±1.5 dBm @ 24 Mbps
25±1.5 dBm @ 36 Mbps
24.5±1.5 dBm @ 48 Mbps
23.5±1.5 dBm @ 54 Mbps

TAP-M310R-1P1R1S and -1P2R1S models:
23±1.5 dBm @ 6 Mbps
23±1.5 dBm @ 9 Mbps
23±1.5 dBm @ 12 Mbps
22±1.5 dBm @ 18 Mbps
22±1.5 dBm @ 24 Mbps
22±1.5 dBm @ 36 Mbps
21.5±1.5 dBm @ 48 Mbps
20.5±1.5 dBm @ 54 Mbps
Transmitter Power for 802.11n (2.4 GHz)

TAP-M310R-NPS-1R and -1P1R models:
26.5±1.5 dBm @ MCS0 20 MHz
26.5±1.5 dBm @ MCS1 20 MHz
25±1.5 dBm @ MCS2 20 MHz
25±1.5 dBm @ MCS3 20 MHz
25±1.5 dBm @ MCS4 20 MHz
24.5±1.5 dBm @ MCS5 20 MHz
23.5±1.5 dBm @ MCS6 20 MHz
23±1.5 dBm @ MCS7 20 MHz
25.5±1.5 dBm @ MCS8 20 MHz
25.5±1.5 dBm @ MCS9 20 MHz
24±1.5 dBm @ MCS10 20 MHz
24±1.5 dBm @ MCS11 20 MHz
24±1.5 dBm @ MCS12 20 MHz
24±1.5 dBm @ MCS13 20 MHz
22.5±1.5 dBm @ MCS14 20 MHz
22±1.5 dBm @ MCS15 20 MHz
26±1.5 dBm @ MCS0 40 MHz
26±1.5 dBm @ MCS1 40 MHz
25.5±1.5 dBm @ MCS2 40 MHz
25±1.5 dBm @ MCS3 40 MHz
24.5±1.5 dBm @ MCS4 40 MHz
24±1.5 dBm @ MCS5 40 MHz
23±1.5 dBm @ MCS6 40 MHz
22.5±1.5 dBm @ MCS7 40 MHz
24±1.5 dBm @ MCS8 40 MHz
24±1.5 dBm @ MCS9 40 MHz
23.5±1.5 dBm @ MCS10 40 MHz
23.5±1.5 dBm @ MCS11 40 MHz
22±1.5 dBm @ MCS12 40 MHz
22±1.5 dBm @ MCS13 40 MHz
21.5±1.5 dBm @ MCS14 40 MHz
21.5±1.5 dBm @ MCS15 40 MHz

TAP-M310R-1P1R1S and -1P2R1S models:
23±1.5 dBm @ MCS0 20 MHz
23±1.5 dBm @ MCS1 20 MHz
22±1.5 dBm @ MCS2 20 MHz
22±1.5 dBm @ MCS3 20 MHz
21.5±1.5 dBm @ MCS4 20 MHz
21±1.5 dBm @ MCS5 20 MHz
20.5±1.5 dBm @ MCS6 20 MHz
19.5±1.5 dBm @ MCS7 20 MHz
23±1.5 dBm @ MCS8 20 MHz
23±1.5 dBm @ MCS9 20 MHz
21±1.5 dBm @ MCS10 20 MHz
21±1.5 dBm @ MCS11 20 MHz
21±1.5 dBm @ MCS12 20 MHz
21±1.5 dBm @ MCS13 20 MHz
20±1.5 dBm @ MCS14 20 MHz
19±1.5 dBm @ MCS15 20 MHz
22.5±1.5 dBm @ MCS0 40 MHz
22.5±1.5 dBm @ MCS1 40 MHz
22.5±1.5 dBm @ MCS2 40 MHz
21.5±1.5 dBm @ MCS3 40 MHz
21±1.5 dBm @ MCS4 40 MHz
20.5±1.5 dBm @ MCS5 40 MHz
20±1.5 dBm @ MCS6 40 MHz
19.5±1.5 dBm @ MCS7 40 MHz
22±1.5 dBm @ MCS8 40 MHz
22±1.5 dBm @ MCS9 40 MHz
21±1.5 dBm @ MCS10 40 MHz
20±1.5 dBm @ MCS11 40 MHz
19±1.5 dBm @ MCS12 40 MHz
19±1.5 dBm @ MCS13 40 MHz
18.5±1.5 dBm @ MCS14 40 MHz
19±1.5 dBm @ MCS15 40 MHz
Transmitter Power for 802.11ac (2.4 GHz, Dual Chain)

TAP-M310R-NPS-1R and -1P1R models:
26±1.5 dBm @ MCS0 20 MHz
26±1.5 dBm @ MCS1 20 MHz
24.5±1.5 dBm @ MCS2 20 MHz
24.5±1.5 dBm @ MCS3 20 MHz
24.5±1.5 dBm @ MCS4 20 MHz
24±1.5 dBm @ MCS5 20 MHz
23±1.5 dBm @ MCS6 20 MHz
22.5±1.5 dBm @ MCS7 20 MHz
22.5±1.5 dBm @ MCS8 20 MHz
25±1.5 dBm @ MCS0 40 MHz
25±1.5 dBm @ MCS1 40 MHz
24±1.5 dBm @ MCS2 40 MHz
24±1.5 dBm @ MCS3 40 MHz
22.5±1.5 dBm @ MCS4 40 MHz
22.5±1.5 dBm @ MCS5 40 MHz
22.5±1.5 dBm @ MCS6 40 MHz
22.5±1.5 dBm @ MCS7 40 MHz
22.5±1.5 dBm @ MCS8 40 MHz
22±1.5 dBm @ MCS9 40 MHz

TAP-M310R-1P1R1S and -1P2R1S models:
22.5±1.5 dBm @ MCS0 20 MHz
22.5±1.5 dBm @ MCS1 20 MHz
22±1.5 dBm @ MCS2 20 MHz
21.5±1.5 dBm @ MCS3 20 MHz
21.5±1.5 dBm @ MCS4 20 MHz
21±1.5 dBm @ MCS5 20 MHz
20±1.5 dBm @ MCS6 20 MHz
19.5±1.5 dBm @ MCS7 20 MHz
19.5±1.5 dBm @ MCS8 20 MHz
22±1.5 dBm @ MCS0 40 MHz
22±1.5 dBm @ MCS1 40 MHz
22±1.5 dBm @ MCS2 40 MHz
21±1.5 dBm @ MCS3 40 MHz
21±1.5 dBm @ MCS4 40 MHz
20±1.5 dBm @ MCS5 40 MHz
19.5±1.5 dBm @ MCS6 40 MHz
19.5±1.5 dBm @ MCS7 40 MHz
19±1.5 dBm @ MCS8 40 MHz
18.5±1.5 dBm @ MCS9 40 MHz
Transmitter Power for 802.11ax (2.4 GHz, Dual Chain)

TAP-M310R-NPS-1R and -1P1R models:
26.5±1.5 dBm @ MCS0 20 MHz
26.5±1.5 dBm @ MCS1 20 MHz
24.5±1.5 dBm @ MCS2 20 MHz
24.5±1.5 dBm @ MCS3 20 MHz
24±1.5 dBm @ MCS4 20 MHz
24±1.5 dBm @ MCS5 20 MHz
23.5±1.5 dBm @ MCS6 20 MHz
23.5±1.5 dBm @ MCS7 20 MHz
22.5±1.5 dBm @ MCS8 20 MHz
22±1.5 dBm @ MCS9 20 MHz
21.5±1.5 dBm @ MCS10 20 MHz
21.5±1.5 dBm @ MCS11 20 MHz
25±1.5 dBm @ MCS0 40 MHz
25±1.5 dBm @ MCS1 40 MHz
24±1.5 dBm @ MCS2 40 MHz
24±1.5 dBm @ MCS3 40 MHz
24±1.5 dBm @ MCS4 40 MHz
22±1.5 dBm @ MCS5 40 MHz
22±1.5 dBm @ MCS6 40 MHz
22±1.5 dBm @ MCS7 40 MHz
22±1.5 dBm @ MCS8 40 MHz
22±1.5 dBm @ MCS9 40 MHz
21.5±1.5 dBm @ MCS10 40 MHz
21.5±1.5 dBm @ MCS11 40 MHz

TAP-M310R-1P1R1S and -1P2R1S models:
22.5±1.5 dBm @ MCS0 20 MHz
22.5±1.5 dBm @ MCS1 20 MHz
21±1.5 dBm @ MCS2 20 MHz
21±1.5 dBm @ MCS3 20 MHz
21±1.5 dBm @ MCS4 20 MHz
20.5±1.5 dBm @ MCS5 20 MHz
20±1.5 dBm @ MCS6 20 MHz
19.5±1.5 dBm @ MCS7 20 MHz
19±1.5 dBm @ MCS8 20 MHz
19±1.5 dBm @ MCS9 20 MHz
18.5±1.5 dBm @ MCS10 20 MHz
18.5±1.5 dBm @ MCS11 20 MHz
22±1.5 dBm @ MCS0 40 MHz
22±1.5 dBm @ MCS1 40 MHz
21±1.5 dBm @ MCS2 40 MHz
21±1.5 dBm @ MCS3 40 MHz
21±1.5 dBm @ MCS4 40 MHz
20.5±1.5 dBm @ MCS5 40 MHz
19.5±1.5 dBm @ MCS6 40 MHz
19.5±1.5 dBm @ MCS7 40 MHz
19±1.5 dBm @ MCS8 40 MHz
18.5±1.5 dBm @ MCS9 40 MHz
18±1.5 dBm @ MCS10 40 MHz
18±1.5 dBm @ MCS11 40 MHz
Receiver Sensitivity for 802.11a

TAP-M310R-NPS-1R and -1P1R models:
Typ. -89 @ 6 Mbps
Typ. -87 @ 9 Mbps
Typ. -86 @ 12 Mbps
Typ. -84 @ 18 Mbps
Typ. -81 @ 24 Mbps
Typ. -78 @ 36 Mbps
Typ. -73 @ 48 Mbps
Typ. -72 @ 54 Mbps

TAP-M310R-1P1R1S and -1P2R1S models:
Typ. -86 @ 6 Mbps
Typ. -84 @ 9 Mbps
Typ. -83 @ 12 Mbps
Typ. -80 @ 18 Mbps
Typ. -77 @ 24 Mbps
Typ. -74 @ 36 Mbps
Typ. -70 @ 48 Mbps
Typ. -68 @ 54 Mbps
Receiver Sensitivity for 802.11n (5 GHz)

TAP-M310R-NPS-1R and -1P1R models:
Typ. -89 dBm @ MCS0 20 MHz
Typ. -86 dBm @ MCS1 20 MHz
Typ. -83 dBm @ MCS2 20 MHz
Typ. -80 dBm @ MCS3 20 MHz
Typ. -76 dBm @ MCS4 20 MHz
Typ. -72 dBm @ MCS5 20 MHz
Typ. -70 dBm @ MCS6 20 MHz
Typ. -69 dBm @ MCS7 20 MHz
Typ. -89 dBm @ MCS8 20 MHz
Typ. -86 dBm @ MCS9 20 MHz
Typ. -84 dBm @ MCS10 20 MHz
Typ. -81 dBm @ MCS11 20 MHz
Typ. -78 dBm @ MCS12 20 MHz
Typ. -74 dBm @ MCS13 20 MHz
Typ. -72 dBm @ MCS14 20 MHz
Typ. -70 dBm @ MCS15 20 MHz
Typ. -86 dBm @ MCS0 40 MHz
Typ. -83 dBm @ MCS1 40 MHz
Typ. -80 dBm @ MCS2 40 MHz
Typ. -77 dBm @ MCS3 40 MHz
Typ. -74 dBm @ MCS4 40 MHz
Typ. -69 dBm @ MCS5 40 MHz
Typ. -68 dBm @ MCS6 40 MHz
Typ. -66 dBm @ MCS7 40 MHz
Typ. -87 dBm @ MCS8 40 MHz
Typ. -83 dBm @ MCS9 40 MHz
Typ. -81 dBm @ MCS10 40 MHz
Typ. -78 dBm @ MCS11 40 MHz
Typ. -75 dBm @ MCS12 40 MHz
Typ. -71 dBm @ MCS13 40 MHz
Typ. -70 dBm @ MCS14 40 MHz
Typ. -68 dBm @ MCS15 40 MHz

TAP-M310R-1P1R1S and -1P2R1S models:
Typ. -85 dBm @ MCS0 20 MHz
Typ. -82 dBm @ MCS1 20 MHz
Typ. -80 dBm @ MCS2 20 MHz
Typ. -76 dBm @ MCS3 20 MHz
Typ. -73 dBm @ MCS4 20 MHz
Typ. -68 dBm @ MCS5 20 MHz
Typ. -67 dBm @ MCS6 20 MHz
Typ. -65 dBm @ MCS7 20 MHz
Typ. -86 dBm @ MCS8 20 MHz
Typ. -83 dBm @ MCS9 20 MHz
Typ. -81 dBm @ MCS10 20 MHz
Typ. -78 dBm @ MCS11 20 MHz
Typ. -75 dBm @ MCS12 20 MHz
Typ. -71 dBm @ MCS13 20 MHz
Typ. -69 dBm @ MCS14 20 MHz
Typ. -66 dBm @ MCS15 20 MHz
Typ. -83 dBm @ MCS0 40 MHz
Typ. -79 dBm @ MCS1 40 MHz
Typ. -77 dBm @ MCS2 40 MHz
Typ. -74 dBm @ MCS3 40 MHz
Typ. -70 dBm @ MCS4 40 MHz
Typ. -66 dBm @ MCS5 40 MHz
Typ. -65 dBm @ MCS6 40 MHz
Typ. -63 dBm @ MCS7 40 MHz
Typ. -84 dBm @ MCS8 40 MHz
Typ. -80 dBm @ MCS9 40 MHz
Typ. -78 dBm @ MCS10 40 MHz
Typ. -74 dBm @ MCS11 40 MHz
Typ. -72 dBm @ MCS12 40 MHz
Typ. -68 dBm @ MCS13 40 MHz
Typ. -67 dBm @ MCS14 40 MHz
Typ. -65 dBm @ MCS15 40 MHz
Receiver Sensitivity for 802.11ac (5 GHz)

TAP-M310R-NPS-1R and -1P1R models:
Typ. -89 dBm @ MCS0 20 MHz
Typ. -86 dBm @ MCS1 20 MHz
Typ. -83 dBm @ MCS2 20 MHz
Typ. -80 dBm @ MCS3 20 MHz
Typ. -78 dBm @ MCS4 20 MHz
Typ. -73 dBm @ MCS5 20 MHz
Typ. -72 dBm @ MCS6 20 MHz
Typ. -70 dBm @ MCS7 20 MHz
Typ. -66 dBm @ MCS8 20 MHz
Typ. -87 dBm @ MCS0 40 MHz
Typ. -83 dBm @ MCS1 40 MHz
Typ. -81 dBm @ MCS2 40 MHz
Typ. -78 dBm @ MCS3 40 MHz
Typ. -75 dBm @ MCS4 40 MHz
Typ. -71 dBm @ MCS5 40 MHz
Typ. -70 dBm @ MCS6 40 MHz
Typ. -68 dBm @ MCS7 40 MHz
Typ. -64 dBm @ MCS8 40 MHz
Typ. -62 dBm @ MCS9 40 MHz
Typ. -84 dBm @ MCS0 80 MHz
Typ. -81 dBm @ MCS1 80 MHz
Typ. -78 dBm @ MCS2 80 MHz
Typ. -75 dBm @ MCS3 80 MHz
Typ. -72 dBm @ MCS4 80 MHz
Typ. -68 dBm @ MCS5 80 MHz
Typ. -66 dBm @ MCS6 80 MHz
Typ. -64 dBm @ MCS7 80 MHz
Typ. -61 dBm @ MCS8 80 MHz
Typ. -59 dBm @ MCS9 80 MHz

TAP-M310R-1P1R1S and -1P2R1S models:
Typ. -86 dBm @ MCS0 20 MHz
Typ. -82 dBm @ MCS1 20 MHz
Typ. -80 dBm @ MCS2 20 MHz
Typ. -77 dBm @ MCS3 20 MHz
Typ. -74 dBm @ MCS4 20 MHz
Typ. -70 dBm @ MCS5 20 MHz
Typ. -68 dBm @ MCS6 20 MHz
Typ. -67 dBm @ MCS7 20 MHz
Typ. -63 dBm @ MCS8 20 MHz
Typ. -83 dBm @ MCS0 40 MHz
Typ. -80 dBm @ MCS1 40 MHz
Typ. -78 dBm @ MCS2 40 MHz
Typ. -74 dBm @ MCS3 40 MHz
Typ. -72 dBm @ MCS4 40 MHz
Typ. -68 dBm @ MCS5 40 MHz
Typ. -66 dBm @ MCS6 40 MHz
Typ. -65 dBm @ MCS7 40 MHz
Typ. -61 dBm @ MCS8 40 MHz
Typ. -59 dBm @ MCS9 40 MHz
Typ. -81 dBm @ MCS0 80 MHz
Typ. -77 dBm @ MCS1 80 MHz
Typ. -75 dBm @ MCS2 80 MHz
Typ. -71 dBm @ MCS3 80 MHz
Typ. -68 dBm @ MCS4 80 MHz
Typ. -65 dBm @ MCS5 80 MHz
Typ. -63 dBm @ MCS6 80 MHz
Typ. -61 dBm @ MCS7 80 MHz
Typ. -57 dBm @ MCS8 80 MHz
Typ. -56 dBm @ MCS9 80 MHz
Receiver Sensitivity for 802.11ax (5 GHz)

TAP-M310R-NPS-1R and -1P1R models:
Typ. -89 dBm @ MCS0 20 MHz
Typ. -86 dBm @ MCS1 20 MHz
Typ. -84 dBm @ MCS2 20 MHz
Typ. -81 dBm @ MCS3 20 MHz
Typ. -78 dBm @ MCS4 20 MHz
Typ. -73 dBm @ MCS5 20 MHz
Typ. -72 dBm @ MCS6 20 MHz
Typ. -70 dBm @ MCS7 20 MHz
Typ. -66 dBm @ MCS8 20 MHz
Typ. -65 dBm @ MCS9 20 MHz
Typ. -61 dBm @ MCS10 20 MHz
Typ. -59 dBm @ MCS11 20 MHz
Typ. -87 dBm @ MCS0 40 MHz
Typ. -84 dBm @ MCS1 40 MHz
Typ. -82 dBm @ MCS2 40 MHz
Typ. -78 dBm @ MCS3 40 MHz
Typ. -75 dBm @ MCS4 40 MHz
Typ. -71 dBm @ MCS5 40 MHz
Typ. -70 dBm @ MCS6 40 MHz
Typ. -68 dBm @ MCS7 40 MHz
Typ. -65 dBm @ MCS8 40 MHz
Typ. -63 dBm @ MCS9 40 MHz
Typ. -59 dBm @ MCS10 40 MHz
Typ. -57 dBm @ MCS11 40 MHz
Typ. -84 dBm @ MCS0 80 MHz
Typ. -81 dBm @ MCS1 80 MHz
Typ. -78 dBm @ MCS2 80 MHz
Typ. -76 dBm @ MCS3 80 MHz
Typ. -72 dBm @ MCS4 80 MHz
Typ. -68 dBm @ MCS5 80 MHz
Typ. -67 dBm @ MCS6 80 MHz
Typ. -65 dBm @ MCS7 80 MHz
Typ. -61 dBm @ MCS8 80 MHz
Typ. -59 dBm @ MCS9 80 MHz
Typ. -55 dBm @ MCS10 80 MHz
Typ. -53 dBm @ MCS11 80 MHz

TAP-M310R-1P1R1S and -1P2R1S models:
Typ. -87 dBm @ MCS0 20 MHz
Typ. -83 dBm @ MCS1 20 MHz
Typ. -81 dBm @ MCS2 20 MHz
Typ. -78 dBm @ MCS3 20 MHz
Typ. -75 dBm @ MCS4 20 MHz
Typ. -71 dBm @ MCS5 20 MHz
Typ. -69 dBm @ MCS6 20 MHz
Typ. -67 dBm @ MCS7 20 MHz
Typ. -64 dBm @ MCS8 20 MHz
Typ. -62 dBm @ MCS9 20 MHz
Typ. -58 dBm @ MCS10 20 MHz
Typ. -56 dBm @ MCS11 20 MHz
Typ. -84 dBm @ MCS0 40 MHz
Typ. -81 dBm @ MCS1 40 MHz
Typ. -79 dBm @ MCS2 40 MHz
Typ. -76 dBm @ MCS3 40 MHz
Typ. -72 dBm @ MCS4 40 MHz
Typ. -63 dBm @ MCS5 40 MHz
Typ. -67 dBm @ MCS6 40 MHz
Typ. -65 dBm @ MCS7 40 MHz
Typ. -62 dBm @ MCS8 40 MHz
Typ. -60 dBm @ MCS9 40 MHz
Typ. -56 dBm @ MCS10 40 MHz
Typ. -54 dBm @ MCS11 40 MHz
Typ. -81 dBm @ MCS0 80 MHz
Typ. -78 dBm @ MCS1 80 MHz
Typ. -75 dBm @ MCS2 80 MHz
Typ. -72 dBm @ MCS3 80 MHz
Typ. -69 dBm @ MCS4 80 MHz
Typ. -65 dBm @ MCS5 80 MHz
Typ. -64 dBm @ MCS6 80 MHz
Typ. -62 dBm @ MCS7 80 MHz
Typ. -58 dBm @ MCS8 80 MHz
Typ. -56 dBm @ MCS9 80 MHz
Typ. -52 dBm @ MCS10 80 MHz
Typ. -50 dBm @ MCS11 80 MHz
Receiver Sensitivity for 802.11b

TAP-M310R-NPS-1R and -1P1R models:
Typ. -94 dBm @ 1 Mbps
Typ. -90 dBm @ 2 Mbps
Typ. -88 dBm @ 5.5 Mbps
Typ. -85 dBm @ 11 Mbps

TAP-M310R-1P1R1S and -1P2R1S models:
Typ. -91 dBm @ 1 Mbps
Typ. -87 dBm @ 2 Mbps
Typ. -85 dBm @ 5.5 Mbps
Typ. -83 dBm @ 11 Mbps
Receiver Sensitivity for 802.11g

TAP-M310R-NPS-1R and -1P1R models:
Typ. -89 dBm @ 6 Mbps
Typ. -87 dBm @ 9 Mbps
Typ. -86 dBm @ 12 Mbps
Typ. -84 dBm @ 18 Mbps
Typ. -81 dBm @ 24 Mbps
Typ. -78 dBm @ 36 Mbps
Typ. -73 dBm @ 48 Mbps
Typ. -72 dBm @ 54 Mbps

TAP-M310R-1P1R1S and -1P2R1S models:
Typ. -86 dBm @ 6 Mbps
Typ. -84 dBm @ 9 Mbps
Typ. -83 dBm @ 12 Mbps
Typ. -81 dBm @ 18 Mbps
Typ. -78 dBm @ 24 Mbps
Typ. -74 dBm @ 36 Mbps
Typ. -70 dBm @ 48 Mbps
Typ. -69 dBm @ 54 Mbps
Receiver Sensitivity for 802.11n (2.4 GHz)

TAP-M310R-NPS-1R and -1P1R models:
Typ. -88 dBm @ MCS0 20 MHz
Typ. -86 dBm @ MCS1 20 MHz
Typ. -83 dBm @ MCS2 20 MHz
Typ. -80 dBm @ MCS3 20 MHz
Typ. -77 dBm @ MCS4 20 MHz
Typ. -72 dBm @ MCS5 20 MHz
Typ. -71 dBm @ MCS6 20 MHz
Typ. -69 dBm @ MCS7 20 MHz
Typ. -90 dBm @ MCS8 20 MHz
Typ. -87 dBm @ MCS9 20 MHz
Typ. -85 dBm @ MCS10 20 MHz
Typ. -82 dBm @ MCS11 20 MHz
Typ. -78 dBm @ MCS12 20 MHz
Typ. -74 dBm @ MCS13 20 MHz
Typ. -73 dBm @ MCS14 20 MHz
Typ. -71 dBm @ MCS15 20 MHz
Typ. -86 dBm @ MCS0 40 MHz
Typ. -84 dBm @ MCS1 40 MHz
Typ. -81 dBm @ MCS2 40 MHz
Typ. -78 dBm @ MCS3 40 MHz
Typ. -74 dBm @ MCS4 40 MHz
Typ. -70 dBm @ MCS5 40 MHz
Typ. -68 dBm @ MCS6 40 MHz
Typ. -67 dBm @ MCS7 40 MHz
Typ. -88 dBm @ MCS8 40 MHz
Typ. -85 dBm @ MCS9 40 MHz
Typ. -83 dBm @ MCS10 40 MHz
Typ. -79 dBm @ MCS11 40 MHz
Typ. -76 dBm @ MCS12 40 MHz
Typ. -72 dBm @ MCS13 40 MHz
Typ. -70 dBm @ MCS14 40 MHz
Typ. -68 dBm @ MCS15 40 MHz

TAP-M310R-1P1R1S and -1P2R1S models:
Typ. -85 dBm @ MCS0 20 MHz
Typ. -82 dBm @ MCS1 20 MHz
Typ. -80 dBm @ MCS2 20 MHz
Typ. -77 dBm @ MCS3 20 MHz
Typ. -73 dBm @ MCS4 20 MHz
Typ. -69 dBm @ MCS5 20 MHz
Typ. -68 dBm @ MCS6 20 MHz
Typ. -66 dBm @ MCS7 20 MHz
Typ. -87 dBm @ MCS8 20 MHz
Typ. -84 dBm @ MCS9 20 MHz
Typ. -82 dBm @ MCS10 20 MHz
Typ. -79 dBm @ MCS11 20 MHz
Typ. -75 dBm @ MCS12 20 MHz
Typ. -71 dBm @ MCS13 20 MHz
Typ. -70 dBm @ MCS14 20 MHz
Typ. -68 dBm @ MCS15 20 MHz
Typ. -83 dBm @ MCS0 40 MHz
Typ. -80 dBm @ MCS1 40 MHz
Typ. -78 dBm @ MCS2 40 MHz
Typ. -74 dBm @ MCS3 40 MHz
Typ. -71 dBm @ MCS4 40 MHz
Typ. -67 dBm @ MCS5 40 MHz
Typ. -65 dBm @ MCS6 40 MHz
Typ. -64 dBm @ MCS7 40 MHz
Typ. -85 dBm @ MCS8 40 MHz
Typ. -81 dBm @ MCS9 40 MHz
Typ. -79 dBm @ MCS10 40 MHz
Typ. -75 dBm @ MCS11 40 MHz
Typ. -72 dBm @ MCS12 40 MHz
Typ. -69 dBm @ MCS13 40 MHz
Typ. -67 dBm @ MCS14 40 MHz
Typ. -65 dBm @ MCS15 40 MHz
Receiver Sensitivity for 802.11ac (2.4 GHz)

TAP-M310R-NPS-1R and -1P1R models:
Typ. -90 dBm @ MCS0 20 MHz
Typ. -86 dBm @ MCS1 20 MHz
Typ. -84 dBm @ MCS2 20 MHz
Typ. -81 dBm @ MCS3 20 MHz
Typ. -78 dBm @ MCS4 20 MHz
Typ. -74 dBm @ MCS5 20 MHz
Typ. -72 dBm @ MCS6 20 MHz
Typ. -71 dBm @ MCS7 20 MHz
Typ. -67 dBm @ MCS8 20 MHz
Typ. -87 dBm @ MCS0 40 MHz
Typ. -84 dBm @ MCS1 40 MHz
Typ. -82 dBm @ MCS2 40 MHz
Typ. -78 dBm @ MCS3 40 MHz
Typ. -75 dBm @ MCS4 40 MHz
Typ. -71 dBm @ MCS5 40 MHz
Typ. -70 dBm @ MCS6 40 MHz
Typ. -68 dBm @ MCS7 40 MHz
Typ. -65 dBm @ MCS8 40 MHz
Typ. -63 dBm @ MCS9 40 MHz

TAP-M310R-1P1R1S and -1P2R1S models:
Typ. -86 dBm @ MCS0 20 MHz
Typ. -83 dBm @ MCS1 20 MHz
Typ. -81 dBm @ MCS2 20 MHz
Typ. -78 dBm @ MCS3 20 MHz
Typ. -75 dBm @ MCS4 20 MHz
Typ. -71 dBm @ MCS5 20 MHz
Typ. -69 dBm @ MCS6 20 MHz
Typ. -67 dBm @ MCS7 20 MHz
Typ. -64 dBm @ MCS8 20 MHz
Typ. -84 dBm @ MCS0 40 MHz
Typ. -81 dBm @ MCS1 40 MHz
Typ. -79 dBm @ MCS2 40 MHz
Typ. -75 dBm @ MCS3 40 MHz
Typ. -72 dBm @ MCS4 40 MHz
Typ. -68 dBm @ MCS5 40 MHz
Typ. -67 dBm @ MCS6 40 MHz
Typ. -65 dBm @ MCS7 40 MHz
Typ. -61 dBm @ MCS8 40 MHz
Typ. -60 dBm @ MCS9 40 MHz
Receiver Sensitivity for 802.11ax (2.4 GHz)

TAP-M310R-NPS-1R and -1P1R models:
Typ. -89 dBm @ MCS0 20 MHz
Typ. -87 dBm @ MCS1 20 MHz
Typ. -84 dBm @ MCS2 20 MHz
Typ. -81 dBm @ MCS3 20 MHz
Typ. -78 dBm @ MCS4 20 MHz
Typ. -74 dBm @ MCS5 20 MHz
Typ. -73 dBm @ MCS6 20 MHz
Typ. -71 dBm @ MCS7 20 MHz
Typ. -67 dBm @ MCS8 20 MHz
Typ. -65 dBm @ MCS9 20 MHz
Typ. -62 dBm @ MCS10 20 MHz
Typ. -60 dBm @ MCS11 20 MHz
Typ. -87 dBm @ MCS0 40 MHz
Typ. -85 dBm @ MCS1 40 MHz
Typ. -83 dBm @ MCS2 40 MHz
Typ. -80 dBm @ MCS3 40 MHz
Typ. -76 dBm @ MCS4 40 MHz
Typ. -72 dBm @ MCS5 40 MHz
Typ. -71 dBm @ MCS6 40 MHz
Typ. -69 dBm @ MCS7 40 MHz
Typ. -65 dBm @ MCS8 40 MHz
Typ. -63 dBm @ MCS9 40 MHz
Typ. -60 dBm @ MCS10 40 MHz
Typ. -58 dBm @ MCS11 40 MHz

TAP-M310R-1P1R1S and -1P2R1S models:
Typ. -87 dBm @ MCS0 20 MHz
Typ. -84 dBm @ MCS1 20 MHz
Typ. -81 dBm @ MCS2 20 MHz
Typ. -78 dBm @ MCS3 20 MHz
Typ. -75 dBm @ MCS4 20 MHz
Typ. -71 dBm @ MCS5 20 MHz
Typ. -70 dBm @ MCS6 20 MHz
Typ. -68 dBm @ MCS7 20 MHz
Typ. -64 dBm @ MCS8 20 MHz
Typ. -62 dBm @ MCS9 20 MHz
Typ. -59 dBm @ MCS10 20 MHz
Typ. -56 dBm @ MCS11 20 MHz
Typ. -85 dBm @ MCS0 40 MHz
Typ. -82 dBm @ MCS1 40 MHz
Typ. -79 dBm @ MCS2 40 MHz
Typ. -76 dBm @ MCS3 40 MHz
Typ. -73 dBm @ MCS4 40 MHz
Typ. -69 dBm @ MCS5 40 MHz
Typ. -68 dBm @ MCS6 40 MHz
Typ. -66 dBm @ MCS7 40 MHz
Typ. -62 dBm @ MCS8 40 MHz
Typ. -60 dBm @ MCS9 40 MHz
Typ. -57 dBm @ MCS10 40 MHz
Typ. -54 dBm @ MCS11 40 MHz
WLAN Operation Mode

Access point
Client
Client-Router
Master
Slave
Sniffer
Antenna Connectors

TAP-M310R-NPS-1R and -1P1R models: 2 x N-type female
TAP-M310R-1P1R1S models: 4 x N-type female
TAP-M310R-1P2R1S models: 8 x N-type female

Standards

All models:
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X)
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3bz for 2.5GBaseT
IEEE 802.1Q for VLAN Tagging

TAP-M310R-1P1R1S and -1P2R1S models only:
IEEE 802.3z for 1000BaseX
10/100/1000/2500BaseT(X) Ports (M12 X-coded 8-pin female connector)

TAP-M310R-NPS-1R, -1P1R models: 1
TAP-M310R-1P1R1S models: 1
TAP-M310R-1P2R1S models: 2
10/100/1000BaseT(X) Ports (M12 X-coded 8-pin female connector)

TAP-M310R-1P1R1S, -1P2R1S models: 2
1000/2500BaseSFP Slots

TAP-M310R-1P1R1S, -1P2R1S models: 2

Management

DHCP Server
DHCP Client
DNS
HTTP
IPv4
LLDP
SMTP
SNMPv1/v2c/v3
Syslog
TCP/IP
Telnet
UDP
VLAN
MXconfig
Security

HTTPS/SSL
RADIUS
SSH
Certificate Management
Time Management

SNTP Client

Filter

ICMP
MAC address
IP protocol
Port-based
Wi-Fi ACL
Client Isolation

Console Port

RS-232 (M12 A-coded 5-pin male connector)

LED Indicators

TAP-M310R-NPS-1R, -1P1R models:
PWR, PWR R, PWR L, SYS, 2.4G, 5G, LAN 1
TAP-M310R-1P1R1S, -1P2R1S models:
PWR, PWR R, PWR L, SYS, 2.4G, 5G, LAN 1, LAN 2, LAN 3, LAN 4, LAN 5, HEAD, TAIL

Buttons

Reset button

Housing

Metal
IP Rating

IP67
Dimensions

TAP-M310R-NPS-1R models: 74.25 x 150 x 130 mm (2.92 x 5.91 x 5.12 in)
TAP-M310R-NPS-1P1R models: 136.65 x 150 x 130 mm (5.38 x 5.91 x 5.12 in)
TAP-M310R-1P1R1S models: 198.75 x 150 x 130 mm (7.83 x 5.91 x 5.12 in)
TAP-M310R-1P2R1S models: 268.15 x 150 x 130 mm (10.56 x 5.91 x 5.12 in)
Weight

TAP-M310R-NPS-1R models: 1,688 g (3.72 lb)
TAP-M310R-NPS-1P1R models: 3,263.5 g (7.19 lb)
TAP-M310R-1P1R1S models: 4,508.5 g (9.94 lb)
TAP-M310R-1P2R1S models: 6,281 g (13.85 lb)
Installation

TAP-M310R-NPS-1R, -1P1R models: Wall mounting, DIN-rail mounting (with optional kit)
TAP-M310R-1P1R1S, -1P2R1S models: DIN-rail mounting

Input Current

TAP-M310R-NPS-1R models: 1.35 A @ 24 VDC
TAP-M310R-NPS-1P1R models:1.35 A @ 24 VDC, 0.3 A @ 110 VDC
TAP-M310R-1P1R1S models: 110 to 220 VAC, 50 to 60 Hz, 0.36 to 0.18 A (max.)
TAP-M310R-1P2R1S models: 110 to 220 VAC, 50 to 60 Hz, 0.62 to 0.31 A (max.)
Input Voltage

TAP-M310R-NPS-1R models: 24 VDC
TAP-M310R-NPS-1P1R models: 24 to 110 VDC
TAP-M310R-1P1R1S, -1P2R1S models: 110 to 220 VAC
Power Connector

TAP-M310R-NPS-1R models: M12 A-coded 4-pin male connector
TAP-M310R-NPS-1P1R models: M12 K-coded 5-pin male connector
TAP-M310R-1P1R1S, -1P2R1S models: M12 K-coded 5-pin male connector
Power Consumption

TAP-M310R-NPS-1R models: 32.4 W (max.)
TAP-M310R-NPS-1P1R models: 33 W (max.)
TAP-M310R-1P1R1S models: 39.6 W (max.)
TAP-M310R-1P2R1S models: 68.2 W (max.)

Operating Temperature

-40 to 75°C (-40 to 167°F)
Storage Temperature (package included)

-40 to 85°C (-40 to 185°F)
Ambient Relative Humidity

5 to 95% (non-condensing)

EMC

EN 61000-6-2/-6-4
EN 55032/35
EMI

CISPR 32, FCC Part 15B Class A
EMS

IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV
IEC 61000-4-6 CS: 10 V/m
IEC 61000-4-8 PFMF: 30 A/m
Safety

IEC 62368-1
UL 62368-1
Cybersecurity

EN 18031-1
Railway

EN 50121-4
EN 50155
Railway Fire Protection

EN 45545-2
Radio

EN 300 328, EN 301 489-1/17, EN 301 893, EN 300 440, FCC

Time

TAP-M310R-NPS-1R models: 2,531,479 hrs
TAP-M310R-NPS-1P1R models: 1,872,508 hrs
TAP-M310R-1P1R1S models: 1,414,473 hrs
TAP-M310R-1P2R1S models: 922,834 hrs
Standards

Telcordia Standard SR-332

Warranty Period

5 years
Details

See www.moxa.com/tw/warranty

下載產品資料表

軟體、韌體和驅動程式

名稱	類型	檔案校驗碼	版本	作業系統	發布日期
Firmware for TAP-M310R Series 41.2 MB	韌體	5C9269B30232B7C4129CCD71AA49F7CA2500AA12ABDCEC78EBEA080B8325FE8A5AC898520B6C6F4C049809AE352559972F6D70EAC9F76549F5C783A44EDDB29E SHA-512	v1.1		2025年10月31日 2025年10月31日版本說明

支援文件

名稱	類型	語言	版本	發布日期
Manual for TAP-M310R Series 14.3 MB	使用者手冊	英文	v1.2	2026年4月17日 2026年4月17日
TAP-M310R 系列產品資料表 4.0 MB	產品資料表	中文	v1.1	2026年1月26日 2026年1月26日
QIG for TAP-M310R Series 3.7 MB	QIG	英文	v1.1	2025年11月14日 2025年11月14日
Declaration of Conformity (cybersecurity) for TAP-M310R 204.4 KB	聲明書	英文	v1.0	2025年11月5日 2025年11月5日
FOSS Statement for TAP-M310R Series 3.3 MB	聲明書	英文	v1.0	2025年7月31日 2025年7月31日
Declaration of Conformity for TAP-M310R Series 376.8 KB	聲明書	英文	v1.0	2025年5月5日 2025年5月5日

可供選擇的機型 (8)

顯示圖片

	比較 TAP-M310R-NPS-1R-EU-CT-T	比較 TAP-M310R-NPS-1R-US-CT-T	比較 TAP-M310R-NPS-1P1R-EU-CT-T	比較 TAP-M310R-NPS-1P1R-US-CT-T
Application	Onboard	Onboard	Onboard	Onboard
Band	EU	US	EU	US
Operating Temp.	-40 to 75°C	-40 to 75°C	-40 to 75°C	-40 to 75°C
	加入詢價查看詢價明細	加入詢價查看詢價明細	加入詢價查看詢價明細	加入詢價查看詢價明細

	比較 TAP-M310R-1P1R1S-EU-CT-T	比較 TAP-M310R-1P1R1S-US-CT-T	比較 TAP-M310R-1P2R1S-EU-CT-T	比較 TAP-M310R-1P2R1S-US-CT-T
Application	Wayside	Wayside	Wayside	Wayside
Band	EU	US	EU	US
Operating Temp.	-40 to 75°C	-40 to 75°C	-40 to 75°C	-40 to 75°C
	加入詢價查看詢價明細	加入詢價查看詢價明細	加入詢價查看詢價明細	加入詢價查看詢價明細

TAP-M310R 系列

Wi-Fi 6 (802.11ax) 鐵路列車對地 IP67 無線 AP/用戶端

特色與優點

認證

簡介

WLAN Interface

WLAN Standards

Frequency Band for US (20 MHz operating channels)

Frequency Band for EU (20 MHz operating channels)

Wireless Security

Transmission Rate

Transmitter Power for 802.11a

Transmitter Power for 802.11n (5 GHz)

Transmitter Power for 802.11ac (5 GHz, Dual Chain)

Transmitter Power for 802.11ax (5 GHz, Dual Chain)

Transmitter Power for 802.11b

Transmitter Power for 802.11g

Transmitter Power for 802.11n (2.4 GHz)

Transmitter Power for 802.11ac (2.4 GHz, Dual Chain)

Transmitter Power for 802.11ax (2.4 GHz, Dual Chain)

Receiver Sensitivity for 802.11a

Receiver Sensitivity for 802.11n (5 GHz)

Receiver Sensitivity for 802.11ac (5 GHz)

Receiver Sensitivity for 802.11ax (5 GHz)

Receiver Sensitivity for 802.11b

Receiver Sensitivity for 802.11g

Receiver Sensitivity for 802.11n (2.4 GHz)

Receiver Sensitivity for 802.11ac (2.4 GHz)

Receiver Sensitivity for 802.11ax (2.4 GHz)

WLAN Operation Mode

Antenna Connectors

Ethernet Interface

Standards

10/100/1000/2500BaseT(X) Ports (M12 X-coded 8-pin female connector)

10/100/1000BaseT(X) Ports (M12 X-coded 8-pin female connector)

1000/2500BaseSFP Slots

Ethernet Software Features

Management

Security

Time Management

Firewall

Filter

Serial Interface

Console Port

LED Interface

LED Indicators

Input/Output Interface

Buttons

Physical Characteristics

Housing

IP Rating

Dimensions

Weight

Installation

Power Parameters

Input Current

Input Voltage

Power Connector

Power Consumption

Environmental Limits

Operating Temperature

Storage Temperature (package included)

Ambient Relative Humidity

Standards and Certifications

EMC

EMI

EMS

Safety

Cybersecurity

Railway

Railway Fire Protection

Radio

MTBF

Time

Standards

Warranty

Warranty Period

Details

軟體、韌體和驅動程式

篩選
