Arm Cortex-A53 quad-core 1.6 GHz

4 GB LPDDR4

Moxa Industrial Linux 3 (Debian 11, kernel 5.10), 2031 EOL
See www.moxa.com/MIL

16 GB eMMC

microSD socket x 1

Auto-sensing 10/100/1000 Mbps ports (M12 X-coded) x 2

V1222-CT-T, V1222-W-CT-T:
RS-232/422/485 ports x 2 (software-selectable, DB9 male connector)

USB 2.0 hosts x 1, type-A connectors

V1222-CT-T, V1222-W-CT-T: QMA x 2

V1222-CT-T, V1222-W-CT-T: QMA x 4

V1222-CT-T, V1222-W-CT-T: QMA x 1

3-pin header output (115200, n, 8, 1)

V1222-CT-T models:
M.2 E-key slot x1 (for Wi-Fi 6)
M.2 B-key slot x1 (for 5G)
mPCIe slot x1 (for LTE)

Note: 5G and LTE cannot be operated at the same time.

V1222-CT-T, V1222-W-CT-T: Nano

V1222-CT-T: 2 for 5G or 2 for LTE
V1222-W-CT-T: 2 for 5G

Reset button

TPM v2.0

V1222-CT-T, V1222-W-CT-T: 2

50 bps to 921.60 kbps

5, 6, 7, 8

1, 1.5, 2

None, Even, Odd, Space, Mark

RTS/CTS, XON/XOFF
ADDC (automatic data direction control) for RS-485
RTS Toggle (RS-232 only)

N/A

TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND

Tx+, Tx-, Rx+, Rx-, GND

Data+, Data-, GND

Tx+, Tx-, Rx+, Rx-, GND

5G NSA and SA bands:
n1 (2100 MHz), n2 (1900 MHz), n3 (1800 MHz), n5 (850 MHz), n7 (2600 MHz), n8 (900 MHz), n20 (800 MHz), n25 (1900 MHz), n28 (700 MHz), n30 (2300 MHz), n38 (2600 MHz), n41 (2500 MHz), n48 (3600 MHz), n66 (1700 MHz), n71 (600 MHz), n75 (1500 MHz), n77 (3700 MHz), n78 (3500 MHz), n79 (4500 MHz)

B1 (2100 MHz), B2 (1900 MHz), B3 (1800 MHz), B4 (1700 MHz), B5 (850 MHz), B7 (2600 MHz), B8 (900 MHz), B12 (700 MHz), B13 (700 MHz), B14 (700 MHz), B17 (700 MHz), B18 (800 MHz), B19 (800 MHz), B20 (800 MHz), B25 (1900 MHz), B26 (850 MHz), B28 (700 MHz), B29 (700 MHz), B30 (2300 MHz), B32 (1500 MHz), B34 (2000 MHz), B38 (2600 MHz), B39 (1900 MHz), B40 (2300 MHz), B41 (2500 MHz), B42 (3500 MHz), B43 (3600 MHz), B46 (5200 MHz), B48 (3600 MHz), B66 (1700 MHz), B71 (600 MHz)

B1 (2100 MHz)
B2 (1900 MHz)
B4 (1700 MHz)
B5 (850 MHz)
B6 (850 MHz)
B8 (900 MHz)
B19 (800 MHz)

Wide-band GNSS: 1559 to 1606 MHz (recommended)
GPS: BW NB GPS 2.046 MHz (centered at 1575.42 MHz)
GLONASS: BW 8.3 MHz approx. (1597.05 to 1606 MHz)
BeiDou: 4.092 MHz BW (1559.05 to 1563.14 MHz)
Galileo: 4.092 MHz BW (centered at 1575.42 MHz)

Active antenna (default)
Passive antenna

Hot start: 1 s
Warm start: 27 s
Cold start: 28 s

Cold starts: -146 dBm
Tracking: -161 dBm
Acquisition: -148 dBm

Minimum 1 Hz

802.11a/b/g/n/ac/ax

2.4 GHz / 6 GHz
2.4 GHz / 5 GHz

Power x 1
System x 1
SIM card indicator x 1

2 ports, 1 per port (10/100/1000 Mbps)

V1222-CT-T, V1222-W-CT-T:
1 LED per port for 2 serial ports

Cellular x 3
Wi-Fi x 3

1

24 to 110 VDC

V1202-CT-T: 0.4 A @ 24 VDC, 0.1A @ 110 VDC
V1222-W-CT-T: 0.48 A @ 24 VDC, 0.105A @ 110 VDC

V1202-CT-T: 7.4 W @ 95% CPU loading
V1222-W-CT-T: 12.7 W (with 5G & Wi-Fi ) @ 95% CPU loading

M12 K-code power connector

Supported

External RTC (real-time clock)

External WDT (watchdog timer)

Metal
SECC

IP40

V1202-CT-T: 150 x 120 x 41 mm
V1222-CT-T / V1222-W-CT-T:
150 x 120 x 50 mm

V1202-CT-T: 665g (without mount ears)
V1222-W-CT-T : 1000g (without mount ears)

Wall mounting (standard)
Desk mounting (with optional kit)
DIN-rail mounting (with optional kit)

With Cellular and Wi-Fi: -40 to 70°C (-40 to 158°F)

-40 to 85°C (-40 to 185°F)

5 to 95% (non-condensing)

EN 55032/35
EN 61000-6-2/-6-4

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV
IEC 61000-4-5 Surge: Power: line-to-line 2 kV, Signal: line-to-ground 2 kV
IEC 61000-4-6 CS: 150 kHz to 80 MHz; Signal: 10 V
IEC 61000-4-8 PFMF

EN 301 908-1 (WCDMA/LTE)
EN 301 489-1/-19 (GPS)
EN 301 489-1/-52 (WCDMA/LTE)
EN 303 413 (GPS)

EN 303 687 (6 GHz)
EN 301 893 (5 GHz)
EN 301 489-1-17
EN 300 328 (2.4 GHz)

FCC
RCM
CE (RED)
UKCA
EN 62311

FCC
CE
UKCA
RCM (V1202-CT-T and V1222-CT-T)
BSMI (V1222-CT-T)

IEC 62368-1
UL 62368-1

EN 45545-2

EN 50155: 2021
EN 50121-4

IEC 60068-2-27
IEC 61373
EN 50155

IEC 60068-2-64
IEC 61373
EN 50155

RoHS, CRoHS, WEEE

V1202-CT-T: 2,755,789 hrs
V1222-CT-T: 1,430,568 hrs
V1222-W-CT-T: 1,324,329 hrs

Telcordia Standard SR332 Issue 4

5 years

See www.moxa.com/jp/warranty
