MOXA

x86 コンピュータ

当社の産業用グレードのファンレスx86コンピュータは、厳しいテストに合格し、厳しい産業規格に完全準拠しています。そのため、過酷な環境でも長期間にわたり信頼性の高い動作を維持することができ、重工業、変電所、ユーティリティ、輸送、石油およびガス、海上用のアプリケーションに最適です。

DA-PWR-200-HV
DA-PWR-200電源モジュールシリーズ

Hot-swappable 100 to 240 VAC/VDC power module with system power input and terminal block for DA-920E Series computers

Power Parameters
  • Input Voltage

    • DA-PWR-200-HV: 100 to 240 VAC/VDC
      DA-PWR-200-WV: 24 to 110 VDC
  • Operating Voltage

    • DA-PWR-200-HV: 90 to 264 VAC/VDC
      DA-PWR-200-WV: 21.6 to 121 VDC
  • Overload Current Protection

    • Supported
  • Overload Voltage Protection

    • Supported
  • Overload Temperature Protection

    • Supported
Physical Characteristics
  • Weight

    • DA-PWR-200-HV: 820g (1.8 lbs)
      DA-PWR-200-WV: 820g (1.8 lbs)
Environmental Limits
  • Operating Temperature

    • -40 to 85°C (-40 to 185°F)
MTBF
  • Time

    • DA-PWR-200-HV: 3,886,750 hrs
      DA-PWR-200-WV: 3,227,791 hrs
  • Standards

    • Telcordia SR-332 Standard Issue 4
Warranty
