Combo Port
RJ45 x 2 and SFP x 2

Proprietary

1500 VDC/min
Between external connection port and system

0.38 A @ 12 VDC

Plastic

42 x 177 x 131.5 mm (1.65 x 6.97 x 5.18 in)

501 g (1.1 lb)

DIN-rail mounting
Rack mounting (with optional kit)

-40 to 75°C (-40 to 167°F)
(with SFP module installed)
Note: Proper airflow is required in an environment with temperature > 65°C

-40 to 85°C (-40 to 185°F)

5 to 95% (non-condensing)

2000 m Please contact Moxa if you require products guaranteed to function properly at higher altitudes.

EN 55032/35
EN 61000-6-2/-6-4

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m
IEC 61000-4-4 EFT: Power: (DC) 1 kV; Signal: 1 kV
IEC 61000-4-5 Surge: Power: (DC) 0.5 kV L-N, 1 kV L/N-PE; Signal: 1 kV; IO: 0.5 kV
IEC 61000-4-6 CS: Power: (DC) 10 V; Signal: 10 Vrms
IEC 61000-4-8 PFMF: 30 A/m

UL 61010-2-201
UL 61010-1

IEC 60068-2-27
Half sine wave; acceleration: 15 g; time: 11 ms

IEC 60068-2-6
DIN-rail mounted:
7 mm peak-peak (p-p) (2 to 8.42 Hz), 1 g (8.42 to 150 Hz)
Rack mounted (with optional kit):
7 mm peak-peak (p-p) (2 to 8.42 Hz), 0.5 g (8.42 to 150 Hz)

ISTA 1A

ISTA 1A

2,800,019 hrs

Telcordia Standard SR-332

5 years

See www.moxa.com/jp/warranty
