1

TCP/IP
IPv4/IPv6
UDP
HTTP
RTP/RTSP
ARP
UPnP
FTP
TFTP
SFTP
NTP Client
DNS
QoS
IGMP v3
ICMP
SNMPv1/v2c/v3
DHCP Opt66/67
HTTPS

User-level password protection

IP address

HTTPS
SSH

1

PoE (IEEE 802.3af)

48 VDC @ 0.097 A

M12 Dcode Ethernet connector

1/2.8-in progressive scan CMOS

VPort P07-2V24M: f=2.4 mm, F2.0, Diagonal 158°, Horizontal 137°, Vertical 76°
VPort P07-2V36M: f=3.6 mm, F1.6, Diagonal 117°, Horizontal 95°, Vertical 50°
VPort P07-2V42M: f=4.2 mm, F1.6, Diagonal 94°, Horizontal 81°, Vertical 44°
VPort P07-2V60M: f=6.0 mm, F1.8, Diagonal 64°, Horizontal 54°, Vertical 30°
VPort P07-2V80M: f=8.0 mm, F1.6, Diagonal 48°, Horizontal 40°, Vertical 22°

Color: 0.2 lux, at F1.2 (Gain High, 50 IRE, 1/30 sec)

Internal

ATW/AWB

Auto, Fixed (1/30 to 1/25000 sec)

Maximum 50 dB (AGC off; DNR on)

Built-in 2D/3D DNR

80 dB

2X, 4X, 8X, 16X

Automatic, 50 Hz, 60 Hz modes

Flip, Mirror, 90°, 180°, 270° rotation

Manual tuning with saturation, sharpness, and contrast

Pan: ±15°, Tilt: 35° to 90° for 2.4mm lens, 20° to 70° for 8.0mm lens, 0° to 90° for other lens (controlled manually)

H.265 (MPEG-H part 2/HEVC), H.264 (ISO/IEC 14496-10/AVC), or MJPEG

via Ethernet

4 independent video streams

Read more

Note: * The FPS can be up to 60 and 50 respectively when the WDR function is disabled.

DynaStream™ support for changing the video frame rate automatically
CBR Pro™ for good image quality in limited bandwidth transmissions
3 privacy mask areas provided
Adjustable image size and quality
Timestamp and text overlay
OSD (On Screen Display) position adjustable
LDC (Lens distortion correction) for less image warp
Maximum of 5 simultaneous unicast connections, 50 multicast clients

ONVIF Profile S, T, M

Camera tampering detection

3 independently configurable areas

JPEG snapshots for pre/trigger/post alarm images

HTTP event servers for setting customized alarm actions

Automatic transfer of stored images via FTP as event-triggered actions

Video buffer for JPEG snapshot images

8 GB

Windows 10 or above

Internet Explorer 11 or above
Chrome: Version 118 or above
Microsoft Edge: Version 118 or above

DirectX 12 or above

Plastic top cover, metal bottom plate
IP66 rain and dust protection
IK10 vandal resistant protection
Transparent PC cover

110 x 47 mm (4.33 x 1.85 in)

310 g (0.68 lb)

Panel mounting

-30 to 60°C (-22 to 140°F)

-40 to 85°C (-40 to 185°F)

5 to 95% (non-condensing)

IEC 60529, IP66

EN 62262, IK10

2000 m

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV
IEC 61000-4-6 CS: 10 V
IEC 61000-4-8 PFMF

IEC 60068-2-31

EN 45545-2

UL 62368-1
BSMI

IEC 60068-2-27, IEC 61373, EN 50155

IEC 60068-2-64, IEC 61373, EN 50155

EN 50155 (complies with a portion of EN 50155 specifications)

5 years

See www.moxa.com/jp/warranty
