1
Relay output with current carrying capacity of 1 A @ 24 VDC

Reset button

1

+13 to +30 V for state 1
-30 to +3 V for state 0
Max. input current: 8 mA

2

IEEE 802.1D-2004 for Spanning Tree Protocol
IEEE 802.1p for Class of Service
IEEE 802.1Q for VLAN Tagging
IEEE 802.1s for Multiple Spanning Tree Protocol
IEEE 802.1w for Rapid Spanning Tree Protocol
IEEE 802.1X for authentication
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X) and 100BaseFX
IEEE 802.3x for flow control
IEEE 802.3z for 1000BaseX
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3ad for Port Trunk with LACP
IEEE802.3cg for 10Base-T1L

8
3-pin terminal block connectors
Ethernet-APL power classes A and C

802.1Q VLAN
BPDU Guard
BPDU Filter
GMRP
GVRP
IGMP v1/v2/v3
Port-based VLAN

EtherNet/IP
Modbus TCP
PROFINET IO Device

LLDP
Back Pressure Flow Control
BOOTP
Port Mirroring
DHCP Option 66/67/82
DHCP Server/Client
Fiber check
Flow control
IPv4/IPv6
RARP
RMON
SCP
SMTP
SNMP Inform
SNMPv1/v2c/v3
Syslog
Telnet
TFTP

Ethernet-like-MIB
MIB-II
Bridge-MIB
P-BRIDGE MIB
Q-BRIDGE-MIB
RMON MIB Groups 1, 2, 3, 9
RSTP MIB

Link Aggregation
MRP
MSTP
RSTP
STP

Broadcast storm protection
HTTPS/SSL
TACACS+
SNMPv3
Sticky MAC
NTP authentication
Port Lock
RADIUS
SSH
SMTP with TLS

NTP Server/Client
SNTP

2048

8 K

64

1 Mbits

4

VID 1 to 4094

USB Type A (for ABC-02 only)

PWR1, PWR2, STATE, FAULT, Gigabit combo port, Ethernet-APL spur port

RS-232 (TxD, RxD, GND), 8-pin RJ45 (115200, n, 8, 1)

Read more

2 removable 2-contact terminal block(s)

24 to 48 VDC, 1 A - 0.5 A (max.)

24/48 VDC
Redundant dual inputs

20 to 60 VDC

Supported

Supported

Metal

IP30

133 x 135 x 111 mm (5.24 x 5.32 x 4.37 in)

1,452 g (3.20 lb)

DIN-rail mounting
Wall mounting (with optional kit)

-40 to 75°C (-40 to 167°F)

-40 to 85°C (-40 to 185°F)

5 to 95% (non-condensing)

Up to 2,000 m
Note: Please contact Moxa if you require products guaranteed to function properly at higher altitudes

UL 61010-2-201
EN IEC 62368-1

EN 61000-6-2/-6-4

FCC Part 15B Class A

IEC 61000-4-2 ESD: Level 3
IEC 61000-4-3 RS: Level 3
IEC 61000-4-4 EFT: Level 3
IEC 61000-4-5 Surge: Level 3
IEC 61000-4-6 CS: Level 3
IEC 61000-4-8 PFMF: Level 3

IEC 60068-2-6
IEC 60068-2-64

IEC 60068-2-27

ISTA 1A (with package)

2,063,466 hrs

Telcordia (Bellcore), GB

5 years

See www.moxa.com/jp/warranty
