2.4 GHz: 802.11b/g/n with 256 QAM support
5 GHz: 802.11a/n/ac Wave 2 with 256 QAM support

AWK-4252A US Models Only:
2.412 to 2.462 GHz (11 channels)
5.180 to 5.240 GHz (4 channels)
5.260 to 5.320 GHz (4 channels) DFS (Dynamic Frequency Selection) channel support: In AP mode, when a radar signal is detected, the device will automatically switch to another channel. However, according to regulations, after switching channels, a 60-second availability check period is required before starting the service.
5.500 to 5.700 GHz (11 channels) DFS (Dynamic Frequency Selection) channel support: In AP mode, when a radar signal is detected, the device will automatically switch to another channel. However, according to regulations, after switching channels, a 60-second availability check period is required before starting the service.
5.745 to 5.825 GHz (5 channels)

AWK-4252A UN Models Only:
2.412 to 2.484 GHz (14 channels)
5.180 to 5.240 GHz (4 channels)
5.260 to 5.320 GHz (4 channels) DFS (Dynamic Frequency Selection) channel support: In AP mode, when a radar signal is detected, the device will automatically switch to another channel.However, according to regulations, after switching channels, a 60-second availability check period is required before starting the service.
5.500 to 5.700 GHz (11 channels) DFS (Dynamic Frequency Selection) channel support: In AP mode, when a radar signal is detected, the device will automatically switch to another channel. However, according to regulations, after switching channels, a 60-second availability check period is required before starting the service.
5.745 to 5.825 GHz (5 channels)
Available channels change depending on the selected country or region code.

WEP encryption (64-bit and 128-bit)
WPA/WPA2/WPA3-Enterprise (IEEE 802.1X/RADIUS, TKIP, AES)
WPA/WPA2/WPA3-Personal

2.4 GHz:
802.11b: 1 to 11 Mbps
802.11g: 6 to 54 Mbps
802.11n: 6.5 to 400 Mbps

5 GHz:
802.11a: 6 to 54 Mbps
802.11n: 6.5 to 300 Mbps
802.11ac: 6.5 to 867 Mbps

24±1.5 dBm @ 6 Mbps
22±1.5 dBm @ 54 Mbps

24±1.5 dBm @ MCS0 20 MHz
21±1.5 dBm @ MCS7 20 MHz
23±1.5 dBm @ MCS0 40 MHz
21±1.5 dBm @ MCS7 40 MHz

23.5±1.5 dBm @ MCS0 20 MHz
20.5±1.5 dBm @ MCS8 20 MHz
23.5±1.5 dBm @ MCS0 40 MHz
20±1.5 dBm @ MCS9 40 MHz
22.5±1.5 dBm @ MCS0 80 MHz
20±1.5 dBm @ MCS9 80 MHz

27.5±1.5 dBm @ 1 Mbps
28±1.5 dBm @ 11 Mbps

28±1.5 dBm @ 6 Mbps
25±1.5 dBm @ 54 Mbps

26±1.5 dBm @ MCS0 20 MHz
24±1.5 dBm @ MCS7 20 MHz
26±1.5 dBm @ MCS0 40 MHz
24.5±1.5 dBm @ MCS7 40 MHz

Typ. -88 @ 6 Mbps
Typ. -71 @ 54 Mbps

Typ. -87 dBm @ MCS0 20 MHz
Typ. -68 dBm @ MCS7 20 MHz
Typ. -83 dBm @ MCS0 40 MHz
Typ. -66 dBm @ MCS7 40 MHz

Typ. -87 dBm @ MCS0 20 MHz
Typ. -64 dBm @ MCS8 20 MHz
Typ. -84 dBm @ MCS0 40 MHz
Typ. -59 dBm @ MCS9 40 MHz
Typ. -81 dBm @ MCS0 80 MHz
Typ. -56 dBm @ MCS9 80 MHz

Typ. -93 dBm @ 1 Mbps
Typ. -86 dBm @ 11 Mbps
Note: Concurrent USB read/write activity on the device may generate interference and may mildly affect receiver sensitivity performance. It is recommended to avoid USB activity on the device in mission-critical applications.

Typ. -88 dBm @ 6 Mbps
Typ. -71 dBm @ 54 Mbps
Note: Concurrent USB read/write activity on the device may generate interference and may mildly affect receiver sensitivity performance. It is recommended to avoid USB activity on the device in mission-critical applications.

Typ. -87 dBm @ MCS0 20 MHz
Typ. -68 dBm @ MCS7 20 MHz
Typ. -84 dBm @ MCS0 40 MHz
Typ. -66 dBm @ MCS7 40 MHz
Note: Concurrent USB read/write activity on the device may generate interference and may mildly affect receiver sensitivity performance. It is recommended to avoid USB activity on the device in mission-critical applications.

Access point
Client
Client-Router
Master
Slave
Sniffer

External, 3/6 dBi
Omni-directional

2 x N-type female

IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X)
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3af for PoE
IEEE 802.3at for PoE
IEEE 802.1Q for VLAN Tagging
IEEE 802.1X for authentication

1

1

DHCP Client
DNS
HTTP
IPv4
LLDP
SMTP
SNMPv1/v2c/v3
Syslog
TCP/IP
Telnet
UDP
VLAN
MXconfig

Port forwarding
Static Route
NAT

HTTPS/SSL
RADIUS
SSH

SNTP Client

ICMP
MAC address
IP protocol
Port-based

RS-232
8-pin RJ45

USB Type A

PWR, LAN1, LAN2, 2.4G, 5G, SYS

2
Max. input current: 8 mA
+13 to +30 V for state 1
+3 to -30 V for state 0

Relay output with current carrying capacity of 1 A @ 24 VDC

Reset button

Metal

66.5 x 157.6 x 244 mm (2.56 x 6.20 x 9.61 in)

IP68

2024 g (4.7 lb)

Wall mounting
DIN-rail mounting (with optional kit)
Pole mounting (with optional kit)

12-48 VDC, 2.2-0.55 A

12 to 48 VDC
Redundant dual inputs
48 VDC Power-over-Ethernet

M12 A-coded 5-pin male connector

28.4 W (max.)

Wide Temp. Models: -40 to 75°C (-40 to 167°F)

-40 to 85°C (-40 to 185°F)

5 to 95% (non-condensing)

EN 61000-6-2/-6-4
EN 55032/35

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 1 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV
IEC 61000-4-6 CS: 10 V/m
IEC 61000-4-8 PFMF: 30 A/m

IEC 60950-1
IEC 62368-1
UL 62368-1

IEC 60068-2-6

EN 300 328, EN 301 489-1/17, EN 301 893, ANATEL, FCC, MIC, NCC, RCM, SRRC, WPC, KC, IC

746,471 hrs

Telcordia SR332

5 years

See www.moxa.com/jp/warranty
