3k VDC or 2k Vrms

Spring-type Euroblock terminal

45ML-5401 Series: 4

45ML-5401 Series: RS-232, RS-422, RS-485-2w

45ML-5401 Series: 300, 600, 1200, 1800, 2400, 4800, 9600, 19200, 38400, 57600, 115200 bps

45ML-5401 Series: 7, 8

45ML-5401 Series: 1, 2

45ML-5401 Series: Even, None, Odd

45ML-5401 Series: RTS/CTS (RS-232 only), XON/XOFF

45ML-5401 Series: 10 kilo-ohm

45ML-5401 Series: ADDC® (automatic data direction control)

TxD, RxD, RTS, CTS, GND

Tx+, Tx-, Rx+, Rx-, GND

Data+, Data-, GND

45ML-5401 Series: 74.1 mA @ 12 VDC
45ML-5401 Series: 37.05 mA @ 24 VDC

45ML-5401 Series: 140.4 mA @ 12 VDC
45ML-5401 Series: 59.8 mA @ 24 VDC

Plastic

26.4 x 99 x 65.5 mm (1.04 x 3.9 x 2.58 in)

45ML-5401 Series: 115 g (0.254 lb)

DIN-rail mounting

Serial cable, 18 to 24 AWG

Serial cable, 9 to 10 mm

Standard Models: -20 to 60°C (-4 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)

-40 to 85°C (-40 to 185°F)

5 to 95% (non-condensing)

Up to 2000 m Please contact Moxa if you require products guaranteed to function properly at higher altitudes.

EN 55032/35

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
IEC 61000-4-4 EFT: Power: 1 kV; Signal: 1 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV
IEC 61000-4-6 CS: 3 V
IEC 61000-4-8 PFMF

IEC 60068-2-27

IEC 60068-2-6

RoHS, CRoHS, WEEE

45ML-5401 Series: 916,671 hrs

Telcordia SR332

5 years

See www.moxa.com/jp/warranty
